8
Manual No. 016-3001-003 125
Advanced Settings and Features
Node Version Information Screen
Version information is available on the Viper Pro field computer. The Node Version Information screen displays
the software version, software revision, and program number of each node currently detected on the CANbus.
To access the Node Version Information screen from the main screen:
1. Touch in the Product Control area on the main screen.
2. Touch within the Miscellaneous area on the CAN Controller Status screen.
3. Touch the Next button. The Node Version Information screen displays.
4. Touch OK or Cancel to return to the CAN Controller Status screen or Prev to go back to the Miscellaneous
Settings screen.
Feature Settings Area for Products 1-3
The information displayed in the Feature Settings area is an overview of the alarm and feature settings for the
selected product control node.
For product nodes or control channels 1 through 3, the following settings will be displayed in the Feature
Settings area:
Note:
The following sections offer descriptions of the various options and settings used with products 1
through 3. For descriptions of the settings used with products 4 and 5, see the Feature Settings
Area for Products 4-5 section on page 128.
• Off Rate % • Bin Level Alarm • Zero Speed Shutoff
• Low Tank • Bin Pressure Alarm • Gate Alarm
• Low Limit • Decimal Shift • Display Smoothing
1.20 (143)
Software
Version Software
Revision Program
Number
