Introduction
Viper Pro Care and Use
Refer to the following guidelines for proper care and use of the Viper Pro field computer.
• Do not apply any type of liquid or glass cleaner directly to the surface of the touch screen. Harsh chemicals
may damage the touch screen. Clean the touch screen and field computer exterior as needed with a soft
cloth dampened with glass cleaner. Apply the cleaner to the cloth and then wipe the screen gently.
• Do not use any type of pointed or sharp instrument on the touch screen. Only a fingertip or approved stylus
should be used when interfacing with the field computer.
• Do not expose the Viper Pro field computer to precipitation or other liquids. Store the computer in a dry
environment when not in use.
• Mount the field computer securely and route cables to avoid tripping hazards and to keep the wires from
pinching or breaking.
• When temperatures are expected to be 10° F [-12° C] or lower, remove the field computer from the vehicle
and store it in a climate controlled environment.
Technical Specifications
CAUTION
U.S. Metric
Dimensions
Height 12.04 in. [30.58 cm]
Width 8.95 in. [22.73 cm]
Depth 2.98 in. [7.57 cm]
Diagonal 10.4 in. [26.42 cm]
Weight 4.7 lbs. 2.13 kg
Environmental
Operating
Temperature
32° F to 158° F 0° C to 70° C
Storage
Temperature
-4° F to 185° F -20° C to 85° C
Power
Operating
Voltage 9 VDC to 28 VDC
Reverse Polarity Protected
Ports
USB 3 (1 on front, 2 on back)
Ethernet 1 (Back)
Amp 2 (Back)
Mounting
Clamp a
(Provided)
a.Designed to secure the field computer to a 1” dia. [2.54 cm] monitor
bar or post.
1.020 in. dia. 2.59 cm dia.
Thumb Screws
(Provided)
1/4”-20 x 1” Long
