CHAPTER
6
Manual No. 016-3001-003 103
Chapter 6
Viper Pro Guidance
Note:
A DGPS receiver capable of outputting GPS messages at 10Hz is required to use the guidance
capabilities of the Seed Hawk Viper Pro.
Guidance Views
The Viper Pro provides two viewing options for guidance control, the ‘Down Field View’ and the ‘Bird’s Eye
View.’
The ‘Down Field View’ shows a three dimensional display of the field much like the view from the vehicle cab.
The ‘Bird’s Eye View’ shows the operation area and the vehicle as viewed from a distance above.
All guidance features can be used in either the ‘Down Field View’ or the ‘Bird’s Eye View’.
