CHAPTER
10
Manual No. 016-3001-003 181
Chapter 10
Remote Calibration
Console
Overview and Connection
The optional Seed Hawk tank calibration kit (P/N 117-0171-302) allows the operator to perform all the
necessary calibration operations from the air cart making calibration of the Seed Hawk system quick and
convenient. The remote tank console allows the operator to prime metering rollers and perform the catch test
while watching the air cart operation which can help the operator make correct system adjustments prior to
starting a seeding operation in a field.
Note:
When performing calibration with the remote tank console, power up the Seed Hawk Viper Pro and
select the Display Program List option when prompted. The Seed Hawk Viper Pro should remain
on the Program Menu Selection screen while using the remote tank console. To display the
Program Menu Selection screen from the Viper Pro main screen, touch Menu, Exit and then
select the Exit to Menu option.
The tank calibration kit requires a hydraulic drive system to connect the remote tank console.
Kit Contents
TABLE 1. Seed Hawk Tank Calibration Kit (P/N 117-0171-302)
WARNING
The metering rollers will turn during the
calibration procedure. Keep away from moving
components when performing a catch test using
the remote tank console.
Be aware of bystanders and alert anyone
around the air cart when performing the
calibration process.
Part/Description Part Number
Console, Remote Tank 063-3001-004
Cable, Remote Tank Calibrator 115-3001-039
