Watlow EZ-ZONE ® RMC Module • 95 • Chapter 4 Setup Page
RMC Module • Setup Page
Dis-
play
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[SFn;A]
[SFn.A] Counter (1 to 4)
Source Function A
Set the type of function
that will be used for the
counter clock signal.
[none] None (61)
[ALM] Alarm (6)
[`CPE] Compare (230)
[`Ctr] Counter (231)
[`dio] Digital I/O (1142)
[Ent;A] Profile Event Out A
(233)
[Ent;b] Profile Event Out B
(234)
[Ent;C] Profile Event Out C
(235)
[Ent;d] Profile Event Out D
(236)
[Ent;E] Profile Event Out E
(247)
[Ent;F] Profile Event Out F
(248)
[Ent;g] Profile Event Out G
(249)
[Ent;h] Profile Event Out H
(250)
[`FUn] Function Key (1001)
[`lgC] Logic (239)
[SoF;1] Special Function Output
1 (1532)
[SoF;2] Special Function Output
2 (1533)
[SoF;3] Special Function Output
3 (1534)
[SoF;4] Special Function Output
4 (1535)
[tMr] Timer (244)
[`uAr] Variable (245)
None 4160
[offset 40]
0x82 (130)
1 to 4
1
- - - - 30001 uint
RWES
[`Si;A]
[ Si.A] Counter (1 to 4)
Source Instance A
Set the instance of the
function selected above.
1 to 250 1 4164
[offset 40]
0x82 (130)
1 to 4
3
- - - - 30003 uint
RWES
[`S2;A]
[ SZ.A] Counter (1 to 4)
Source Zone A
Set the zone of the func-
tion selected above.
0 to 16 0 4168
[offset 40]
0x82 (130)
1 to 4
5
- - - - 30005 uint
RWES
[sas;A]
[SAS.A] Counter (1 to 4)
Source Active State A
Set what output state
will indicate on.
[both] Both (130
[high] High (37)
[LoW] Low (53)
High 4180
[offset 40]
0x82 (130)
1 to 4
0xB (11)
- - - - 30011 uint
RWES
Note:
Some values will be rounded off to fit in the four-character display .
Full values can be read with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E: EEPROM
S: User Set
