Watlow EZ-ZONE ® RMC Module • 53 • Chapter 3 Operations Page
RMC Module • Operations Page
Display
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[`Su;E]
[ Su.E] Math (1 to 8)
Source Value E
View the value of
Source E.
[`off] Off (62)
[``on] On (63)
- - - - 2878
[offset 70] 0x7D
(125)
1 to 8
0x14 (20)
- - - - 25020 uint
R
[oFSt]
[oFSt] Math (1 to 8)
Offset
Set an offset to be ap-
plied to this function's
output.
-1,999.000 to 9,999.000°F or
units
-1,128.000 to 5,537.000°C
0 2884
[offset 70] 0x7D
(125)
1 to 8
0x17 (23)
- - - - 25023 float
RWES
[``o;u]
[ o.v] Math (1 to 8)
Output Value
View the value of this
function's output.
-1,999.000 to 9,999.000°F or
units
-1,128.000 to 5,537.000°C
- - - - 2882
[offset 70] 0x7D
(125)
1 to 8
0x16 (22)
- - - - 25022 float
R
No Dis-
play
Math (1 to 8)
Error
Read reported cause for
logic error
None (61)
Open (65)
Shorted (127)
Measurement Error (140)
Bad Cal Data (139)
Ambient Error (9)
RTD Error (141)
Fail (32)
Math Error (1423)
Not Sourced (246)
Stale (1617) - - - - 2896
[offset 70] 0x7D
(125)
1 to 8
0x1D (29)
- - - - 25029 uint
R
[`SoF]
[oPEr]
Special Output Function Menu
[`Su;A]
[ uS.A] Special Output Function
(1 to 4)
Source Value A
View the value of
Source A.
-1,999.000 to 9,999.000°F or
units
-1,128.000 to 5,537.000°C
- - - - 4972
[offset 80] 0x87
(135)
1 to 4
7
- - - - 35007 float
R
[`Su;b]
[ Su.b] Special Output Function
(1 to 4)
Source Value B
View the value of
Source B.
-1,999.000 to 9,999.000°F or
units
-1,128.000 to 5,537.000°C
- - - - 4974
[offset 80] 0x87
(135)
1 to 4
8
- - - - 35008 float
R
[`o;u1]
[ o.v1] Special Output Function
(1 to 4)
Output Value 1
View the value of this
function's Output 1.
-1,999.000 to 9,999.000°F or
units
-1,128.000 to 5,537.000°C
- - - - 4978
[offset 80] 0x87
(135)
1 to 4
0xA (10)
- - - - 35010 float
R
No Dis-
play
Special Output Function
(1 to 4)
Error 1
View reported cause for
output malfunction.
None (61)
Open (65)
Shorted (127)
Measurement error (140)
Bad calibration data (139)
Ambient error (9)
RTD error (14)
Fail (32)
Math error (1423)
Not sourced (246)
Stale (1617)
Can't process (1659)
- - - - 4980
[offset 80] 0x87
(135)
1 to 4
0x0B (11)
- - - - 35011 uint
R
Note:
Some values will be rounded off to fit in the four-character display . Full values can be
read with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0
and above .
R: Read
W: Write
E: EEPROM
S: User Set
