Watlow EZ-ZONE RMC User Manual
Page 83
Watlow EZ-ZONE
®
RMC Module
•
80
•
Chapter 4 Setup Page
RMC Module • Setup Page
Dis-
play
Parameter Name
Description
Range
Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[SP;Lo]
[SP.Lo]
Control Loop (1 to 4)
Set Point Open Limit
Low
Set the minimum value
of the open-loop set point
range.
-100.0 to 100.0%
-100
2508
[offset 80]
0x6B
(107)
1 to 4
5
54
7005
float
RWES
[SP;hi]
[SP.hi]
Control Loop (1 to 4)
Set Point Open Limit
High
Set the maximum value
of the open-loop set point
range.
-100.0 to 100.0%
100
2510
[offset 80]
0x6B
(107)
1 to 4
6
55
7006
float
RWES
[`o;SP]
[ o.SP]
Control Loop (1 to 4)
Open Loop Set Point
**
Set a fixed level of
output power when
in manual (open-loop)
mode.
-100.0 to 100.0% (heat and
cool) 0 to 100.0% (heat only)
-100.0 to 0% (cool only)
0.0
2502
[offset
80]
0x6B
(107)
1 to 4
2
51
7002
float
RWES
[`C;M]
[ C.M]
Control Loop (1 to 4)
Control Mode **
Select the method that
this loop will use to
control.
[`off]
Off (62)
[AUto]
Auto (10)
[MAn]
Manual (54)
Auto
2220
[offset
70]
0x97
(151)
1 to 4
1
63
8001
uint
RWES
Note:
Some values will be rounded off to fit in the four-character display .
Full values can be read with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E:
EEPROM
S:
User Set
