Watlow EZ-ZONE ® RMC Module • 193 • Chapter 7 Features
[P;Str] Profile Start : 1 to 25
[P;ACr] Profile Action Request : None, Profile, Pause, Resume, Terminate
[`StP]
Current Step : 0 to 250
[SUb;S]
Current Subroutine Step : 0 to 150
[t;SP1] [t;SP2] [t;SP3] [t;SP4] Target Set Point Loop 1 to 4
[P;SP1] [P;SP2] [P;SP3] [P;SP4] Produced SP ( Active Set Point) 1 to 4 : -1,999.000 to 9,999.000
[Ent1] [Ent2] [Ent3] [Ent4] [Ent5] [Ent6] [Ent7] [Ent8]
Event (State Output) 1 to 8 : Off, On
[``JC] Jump Count Remaining : 0 to 9,999
[`Sti]
Step Time Remaining : 0 to 9,999 seconds
[P;StA]
Profile Status Menu
[oPEr]
Operation Page
[gSE1] [gSd2] [gSd3] [gSd4] Guaranteed Soak Enable 1 to 4 : Off, On
[StPt] Step Number : 1 to 250
[CM;1] [CM;2] [CM;3] [CM;4]
Control Mode Loop 1 to 4 : Off, Auto, Manual
[t;SP1] [t;SP2] [t;SP3] [t;SP4]
Target Set Point Loop 1 to 4 : -1,999.000 to 9,999.000
[hoUr] Hours : 0 to 99
[Min] Minutes : 0 to 59
[SEC] Seconds : 0 to 59
[rAtE] Rate : 0 to 9,999.000
[P;E1] [P;E2] [P;E3] [P;E4] Step Wait For Process Enable 1 to 4 : Off, Greater Than, Less Than
[W;P1] [W;P2] [W;P3] [W;P4] Wait For Process 1 to 4 : -1,999.000 to 9,999.000
[WE;1] [WE;2] [WE;3] [WE;4] Wait Event 1 to 4 : None, Off, On
[``SC] Subroutine Count : 1 to 9,999
[``JS]
Jump Step : 1 to 250
[``JC] Jump Count : 0 to 9,999
[`End] End Type : Off, Hold, User
[Ent1] [Ent2] [Ent3] [Ent4] [Ent5] [Ent6] [Ent7] [Ent8] Event 1 to 8 : Off, On, Unchanged
[``SS] Subroutine Step : 1 to 15
[``P_]
Profile Menu
[ProF]
Profiling Page
[styp] Current Step Type : Unused Step, Time or Rate, Soak, Wait For Process or Event, Wait for Time,
State, Subroutine Step, Jump Loop, End
[styp] Step Type : Unused Step, Time or Rate, State, Soak, Wait For Process & Event, Wait for Time,
Subroutine Step, Jump Loop, End
[dow] Day of Week : Sunday, Monday, Tuesday, Wednesday, Thursday, Friday, Saturday, Week Days,
Every Day
