Watlow EZ-ZONE RMC - Manual (Page 21)

Watlow EZ-ZONE ® RMC Module • 18 • Chapter 2 Install and Wire
Controller Module (RMCxxxxxxxxxxxx)
Slot A Slot B Slot D Slot E Terminal Function Configuration
Inputs Universal, RTD, Potentiometer and Thermistor Inputs 1 - 4
1 2 3 4
T1
S1
R1
T2
S2
R2
T3
S3
R3
T4
S4
R4
T_ (RTD) or current +S_ (RTD), thermocou-
ple -, current -, potentiometer or volts -
R_ (RTD), thermocouple + or volts +, poten-
tiometer wiper
Universal/Thermistor Input
Part # Digits 4, 6, 8, 10
Input 1: RMC[1,2,3,4,5,6]xxxxxxxxxxx
Input 2: RMCxx[1,2,5,6]xxxxxxxxx
Input 3: RMCxxxx[1,2,5,6]xxxxxxx
Input 4: RMCxxxxxx[1,2,5,6]xxxxx
Current Transformer Inputs 1 - 4
T1
S1
T2
S2
T3
S3
T4
S4
mA ac
mA ac
Current Transformer
Part # Digits 4, 6, 8, 10
Input 1: RMC[7]xxxxxxxxxxx
Input 2: RMCxx[7]xxxxxxxxx
Input 3: RMCxxxx[7]xxxxxxx
Input 4: RMCxxxxxx[7]xxxxx
Digital Inputs 7 - 12
B7
D7
D8
D9
D10
D11
D12
Z7
Common
dc +input
dc +input
dc +input
dc +input
dc +input
dc +input
Internal Supply
Digital Inputs/Outputs
Part # Digit 11
Slot A: Option not valid
Slot B: Option not valid
Slot D: Option not valid
Slot E: RMCxxxxxxx[C]xxxx
Outputs Switched dc / Open Collector Outputs 1, 3, 5 and 7
1 2 3 4 5 6 7 8
X1
W1
Y1
X3
W3
Y3
X5
W5
Y5
X7
W7
Y7
common
dc- (open collector)
dc+
Switched DC/Open Collector
Part # Digits 5, 7, 9, 11
Output 1: RMCx[U,D,E,F,G]xxxxxxxxxx
Output 3: RMCxxx[U,D,E,F,G]xxxxxxxx
Output 5: RMCxxxxx[U,D,E,F,G]xxxxxx
Output 7: RMCxxxxxxx[U,D,E,F,G]xxxx
Switched dc Outputs 2, 4, 6 and 8
W2
Y2
W4
Y4
W6
Y6
W8
Y8
dc-
dc+
Switched DC
Part # Digits 5, 7, 9, 11
Output 2: RMCx[E,K,P]xxxxxxxxxx
Output 4: RMCxxx[E,K,P]xxxxxxxx
Output 6: RMCxxxxx[E,K,P]xxxxxx
Output 8: RMCxxxxxxx(E,K,P]xxxx
Universal Process Outputs 1, 3, 5 and 7
F1
G1
H1
F3
G3
H3
F5
G5
H5
F7
G7
H7
voltage or current -
voltage +
current +
Universal Process
Part # Digits 5, 7, 9, 11
Output 1: RMCx[N,P,R,S]xxxxxxxxxx
Output 3: RMCxxx[N,P,R,S]xxxxxxxx
Output 5: RMCxxxxx[N,P,R,S]xxxxxx
Output 7: RMCxxxxxxx[N,P,R,S]xxxx
Form C - Mechanical Relay Outputs 1, 3, 5 and 7
L1
K1
J1
L3
K3
J3
L5
K5
J5
L7
K7
J7
normally open
common
normally closed
Mechanical Relay 5 A, Form C
Part # Digits 5, 7, 9, 11
Output 1: RMCx[H,J,K,L,M]xxxxxxxxxx
Output 3: RMCxxx[H,J,K,L,M]xxxxxxxx
Output 5: RMCxxxxx[H,J,K,L,M]xxxxxx
Output 7: RMCxxxxxxx[H,J,K,L,M]xxxx
Wiring
