Watlow EZ-ZONE ® RMC Module • 138 • Chapter 5 Profiling Page
RMC Module • Profile Page
Display
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data Type
& Read/
Write
[W;P4]
[W.P4] Subroutine Step (1 to
150)
Wait For Process 4
Enter a value that
must be satisfied
which is specified by
Source H in Profile
Setup.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
0.0°F or
units
-18.0°C
30504
[offset 86]
0x69
(105)
1 to (250)
0x21 (33)
- - - - 5033 float
RWE
[WE;1]
[WE.1] Subroutine Step (1 to
150)
Wait Event 1
Enter a state that
must be satisfied
which is specified by
Source A in Profile
Setup.
[nonE] None (61)
[``on] On (63)
[`oFF] Off (62)
None 30482
[offset 86]
0x69
(105)
1 to (150)
0x16 (22)
- - - - 5022 uint
RWE
[WE;2]
[WE.2] Subroutine Step (1 to
150)
Wait Event 2
Enter a state that
must be satisfied
which is specified by
Source B in Profile
Setup.
[nonE] None (61)
[``on] On (63)
[`oFF] Off (62)
None 30484
[offset 86]
0x69
(105)
1 to (150)
0x17 (23)
- - - - 5023 uint
RWE
[WE;3]
[WE.3] Subroutine Step (1 to
150)
Wait Event 3
Enter a state that
must be satisfied
which is specified by
Source C in Profile
Setup.
[nonE] None (61)
[``on] On (63)
[`oFF] Off (62)
None 30486
[offset 86]
0x69
(105)
1 to (150)
0x18 (24)
- - - - 5024 uint
RWE
[WE;4]
[WE.4] Subroutine Step (1 to
150)
Wait Event 4
Enter a state that
must be satisfied
which is specified by
Source D in Profile
Setup.
[nonE] None (61)
[``on] On (63)
[`oFF] Off (62)
None 30488
[offset 86]
0x69
(105)
1 to (150)
0x19 (25)
- - - - 5025 uint
RWE
[dow]
[doW] Subroutine Step (1 to
150)
Day of Week
If step type is Wait
for Time, select day
of week for profile to
proceed.
[``Ed] Every Day (1567)
[`Wd] Week Days (1566)
[Mon] Monday (1559)
[`tue] Tuesday (1560)
[Wed] Wednesday (1561)
[thUr] Thursday (1562)
[`Fri] Friday (1563)
[`Sat] Saturday (1564)
[`sun] Sunday (1565)
Every
Day
30508
[offset 86]
0x69
(105)
1 to (150)
0x23 (35)
- - - - 5035 uint
RWE
[gSE1]
[gSE1] Subroutine Step (1 to
150)
Guaranteed Soak
Enable 1
Select if profile should
pause while process 1
deviates from devia-
tion band.
[`oFF] Off (62)
[``on] On (63)
Off 30510
[offset 86]
0x69
(105)
1 to (150)
0x24 (36)
- - - - 5036 uint
RWE
Note: Some values will be rounded off to fit in the four-character display . Full values
can be read with other interfaces .
If there is only one instance of a menu, no submenus will appear .
R: Read
W: Write
E: EEPROM
S: User Set
