Watlow EZ-ZONE ® RMC Module • 42 • Chapter 3 Operations Page
RMC Module • Operations Page
Display
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[`Su;C]
[ Su.C] Process Value (1 to 4)
Source Value C
View the value of Source
C.
-1,999.000 to 9,999.000°F or
units
-1,128.000 to 5,537.000°C
- - - - 3434
[offset 70]
0x7E (126)
1 to 4
0x12 (18)
- - - - 26018 float
R
[`Su;d]
[ Su.d] Process Value (1 to 4)
Source Value D
View the value of Source
D.
-1,999.000 to 9,999.000°F or
units
-1,128.000 to 5,537.000°C
- - - - 3436
[offset 70]
0x7E (126)
1 to 4
0x13 (19)
- - - - 26019 float
R
[`Su;E]
[ Su.E] Process Value (1 to 4)
Source Value E
View the value of Source
E.
[`off] Off (62)
[``on] On (63)
- - - - 3438
[offset 70]
0x7E (126)
1 to 4
0x14 (20)
- - - - 26020 float
R
[oFSt]
[oFSt] Process Value (1 to 4)
Offset
Set an offset to be ap-
plied to this function's
output.
-1,999.000 to 9,999.000°F or
units
-1,128.000 to 5,537.000°C
0 3444
[offset 70]
0x7E (126)
1 to 4
0x17 (23)
- - - - 26023 float
RWES
[``o;u]
[ o.u] Process Value (1 to 4)
Output Value
View the value of this
function block's output.
-1,999.000 to 9,999.000°F or
units
-1,128.000 to 5,537.000°C
- - - -
3442
[offset 70]
0x7E (126)
1 to 4
0x16 (22)
- - - - 26022 float
R
No Dis-
play
Process Value (1 to 4)
Error
View reported cause
for Process output mal-
function.
None (61)
Open (65)
Shorted (127)
Measurement error (140)
Bad calibration data (139)
Ambient error (9)
RTD error (14)
Fail (32)
Math error (1423)
Not sourced (246)
Stale (1617)
- - - - 3452
[offset 70]
0x7E
(126)
1 to 4
0x1B (27)
- - - - 26027 uint
R
[`dio]
[oPEr]
Digital Input/Output Menu
[`do;S]
[ do.S] Digital Output (7 to 12)
Output State
View the state of this
output.
[`off] Off (62)
[``on] On (63)
- - - - 1212
[offset 30]
0x6A (106)
7 to C (12)
7
90 6007 uint
R
[`di;S]
[ di.S] Digital Input (7 to 12)
Input State
View this event input
state.
[`off] Off (62)
[``on] On (63)
- - - - 1220
[offset 30]
0x6A (106)
7 to C (12)
0xB (11)
- - - - 6011 uint
R
Note:
Some values will be rounded off to fit in the four-character display . Full values can be
read with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0
and above .
R: Read
W: Write
E: EEPROM
S: User Set
