Watlow EZ-ZONE ® RMC Module • 58 • Chapter 3 Operations Page
RMC Module • Operations Page
Display
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[Ent1]
[Ent1] Profile Status
*Active Event Out-
put 1
View or change the
event output states.
[`off] Off (62)
[``on] On (63)
Off 5306 0x7A
(122)
1
0xE (14)
- - - - 22014 uint
RW
[Ent2]
[Ent2] Profile Status
*Active Event Out-
put 2
View or change the
event output states.
[`off] Off (62)
[``on] On (63)
Off 5308 0x7A
(122)
1
0xF (15)
- - - - 22015 uint
RW
[Ent3]
[Ent3] Profile Status
*Active Event Out-
put 3
View or change the
event output states.
[`off] Off (62)
[``on] On (63)
Off 5310 0x7A
(122)
1
0x10 (16)
- - - - 22016 uint
RW
[Ent4]
[Ent4] Profile Status
*Active Event Out-
put 4
View or change the
event output states.
[`off] Off (62)
[``on] On (63)
Off 5312 0x7A
(122)
1
0x11 (17)
- - - - 22017 uint
RW
[Ent5]
[Ent5] Profile Status
*Active Event Out-
put 5
View or change the
event output states.
[`off] Off (62)
[``on] On (63)
Off 5314 0x7A
(122)
1
0x12 (18)
- - - - 22018 uint
RW
[Ent6]
[Ent6] Profile Status
*Active Event Out-
put 6
View or change the
event output states.
[`off] Off (62)
[``on] On (63)
Off 5316 0x7A
(122)
1
0x13 (19)
- - - - 22019 uint
RW
[Ent7]
[Ent7] Profile Status
*Active Event Out-
put 7
View or change the
event output states.
[`off] Off (62)
[``on] On (63)
Off 5318 0x7A
(122)
1
0x14 (20)
- - - - 22020 uint
RW
[Ent8]
[Ent8] Profile Status
*Active Event Out-
put 8
View or change the
event output states.
[`off] Off (62)
[``on] On (63)
Off 5320 0x7A
(122)
1
0x15 (21)
- - - - 22021 uint
RW
[``JC]
[ JC] Profile Status
Jump Count Remain-
ing
View the jump counts
remaining for the cur-
rent loop. In a profile
with nested loops, this
may not indicate the
actual jump counts re-
maining.
0 to 9,999 - - - - 5298 0x7A
(122)
1
0xA (10)
- - - - 22010 uint
R
No Dis-
play
Profile Status
Current File
Indicates current file
being executed.
1 to 25
0 (none)
- - - - 5284 0x7A
(122)
1
3
- - - - 22003 uint
R
Note:
Some values will be rounded off to fit in the four-character display . Full values can be
read with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0
and above .
R: Read
W: Write
E: EEPROM
S: User Set
