Watlow EZ-ZONE

RMC Module

•

Chapter 2 Install and Wire

Controller Module (RMCxxxxxxxxxxxx)

Slot A

Slot B

Slot D

Slot E

Terminal Function

Configuration

Outputs (cont.)

NO-ARC Form A - Mechanical Relay Outputs 2, 4, 6 and 8

normally open

common

NO-ARC 15 A, Form A
Part # Digits 5, 7, 9, 11

Output 2: RMCx[D,J,Y]xxxxxxxxxx

Output 4: RMCxxx[D,J,Y]xxxxxxxx

Output 6: RMCxxxxx[D,J,Y]xxxxxx

Output 8: RMCxxxxxxx[D,J,Y]xxxx

Form A - Mechanical Relay Outputs 2, 4, 6 and 8

normally open

common

Mechanical Relay 5 A, Form A
Part # Digits 5, 7, 9, 11

Output 2: RMCx[B,F]xxxxxxxxxx

Output 4: RMCxxx[B,F]xxxxxxxx

Output 6: RMCxxxxx[B,F]xxxxxx

Output 8: RMCxxxxxxx[B,F]xxxx

Solid State Relay Outputs 1 - 8

normally open

common

Solid-State Relay 0.5 A, Form A

Part # Digits 5, 7, 9, 11

Output 1: RMCx[G,M,S,T,Y,Z]xxxxxxxxxx

Output 2: RMCx[G,M,S,T,Y,Z]xxxxxxxxxx

Output 3: RMCxxx[G,M,S,T,Y,Z]xxxxxxxx

Output 4: RMCxxx[G,M,S,T,Y,Z]xxxxxxxx

Output 5: RMCxxxxx[G,M,S,T,Y,Z]xxxxxx

Output 6: RMCxxxxx[G,M,S,T,Y,Z]xxxxxx

Output 7: RMCxxxxxxx[G,M,S,T,Y,Z]xxxx

Output 8: RMCxxxxxxx[G,M,S,T,Y,Z]xxxx

Digital Outputs 7 - 12

D10

D11

D12

Common

open collector/ switched dc

Internal Supply

Digital Inputs/Outputs
Part # Digit 11

Slot A: Option not valid
Slot B: Option not valid
Slot D: Option not valid
Slot E: RMCxxxxxxx[C]xxxx

Power and Communications

Slot C

Terminal Function

Configuration

Power input: ac or dc+

Power input: ac or dc-

All

Standard Bus EIA-485 common

Standard Bus EIA-485 T-/R-

Standard Bus EIA-485 T+/R+

Standard Bus

Part # Digit 13

RMCxxxxxxxxxAxx

Standard Bus or Modbus RTU EIA-485 common

Standard Bus or Modbus RTU EIA-485 T-/R-

Standard Bus or Modbus RTU EIA-485 T+/R+

Standard Bus or Modbus

Part # Digit 13

RMCxxxxxxxxx1xx

Inter-module Bus
