Watlow EZ-ZONE ® RMC Module • 114 • Chapter 4 Setup Page
RMC Module • Setup Page
Dis-
play
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[`o;S3]
[ o.S3] Special Output (1 to 4)
Output 3 Size
0 to 9,999 0 5018
[offset 80]
0x87 (135)
1 to 4
0x1E (30)
- - - - 35030 float
RWES
[`o;S4]
[ o.S4] Special Output (1 to 4)
Output 4 Size
0 to 9,999 0 5020
[offset 80]
0x87 (135)
1 to 4
0x1F (31)
- - - - 35031 float
RWES
[`t;dL]
[ t.dL] Special Output (1 to 4)
Time Delay
If Function is set to Se-
quencer:
• Set in seconds to rep-
resent the minimum
span of time that
must elapse between
the turn on of one
(on-off) output to the
next.
0 to 9,999 seconds 0 5010
[offset 80]
0x87 (135)
1 to 4
0x1A (26)
- - - - 35026 uint
RWES
[`ot;o]
[ ot.o] Special Output (1 to 4)
Output Order
If Function is set to Se-
quencer:
• Set to Linear to turn
the on-off outputs
on in the same order
every time. Select
Progressive to rotate
the order to balance
usage and wear on
contactors and heat-
ers.
[`Lin] Linear (1509)
[`Pro] Progressive (1510)
Linear 5012
[offset 80]
0x87 (135)
1 to 4
0x1B (27)
- - - - 35027 uint
RWES
[`uAr]
[`Set]
Variable Menu
[tyPE]
[tyPE] Variable 1 to 8
Data Type
Set the variable's data
type.
[AnLg] Analog (1215)
[`Dig] Digital (1220)
Analog 4800
[offset 20]
0x66 (102)
1 to 8
1
210 2001 uint
RWES
[Unit]
[Unit] Variable 1 to 8
Units
Set the variable's units.
Note:
Units are always in de-
grees F when used for
temperature
[`A;tp] Absolute Temperature
(1540)
[`r;tp] Relative Temperature
(1541)
[PWr] Power (73)
[`Pro] Process (75)
[``rh] Relative Humidity
(1538)
[nonE] None (61)
Absolute
Temper-
ature
4812
[offset 20]
0x66 (102)
1 to 8
7
- - - - 2007 uint
RWES
[`Dig]
[ dig] Variable 1 to 8
Digital
Set the variable's value.
[`oFF] Off (62)
[``on] On (63)
Off 4802
[offset 20]
0x66 (102)
1 to 8
2
211 2002 uint
RWES
[anLg]
[AnLg] Variable 1 to 8
Analog
Set the variable's value.
-1,999.000 to 9,999.000 0.0 4804
[offset 20]
0x66 (102)
1 to 8
3
212 2003 float
RWES
Note:
Some values will be rounded off to fit in the four-character display .
Full values can be read with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E: EEPROM
S: User Set
