Watlow EZ-ZONE ® RMC Module • 48 • Chapter 3 Operations Page
RMC Module • Operations Page
Display
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[`a;st]
[ A.St] Alarm (1 to 8)
Alarm State
Current state of alarm
Startup (88)
None (61)
Blocked (12)
Alarm low (8)
Alarm high (7)
Error (28) - - - - 1756
[offset 60] 0x6D
(109)
1 to 8
9
- - - - 9009 uint
R
No Dis-
play
Alarm (1 to 8)
Alarm Clearable
Read to see if alarm
can be cleared.
[``no] No (59)
[`YES] Yes (106)
- - - - 1762
[offset 60] 0x6D
(109)
1 to 8
0xC (12)
- - - - 9012 uint
R
No Dis-
play
Alarm (1 to 8)
Silenced
Read to see if alarm is
active but has been si-
lenced by Alarm Silence
Request.
Yes (106)
No (59)
- - - - 1760
[offset 60] 0x6D
(109)
1 to 4
0x0B (11)
- - - - 9011 uint
R
No Dis-
play
Alarm (1 to 8)
Latched
Read to see if alarm is
currently latched.
Yes (106)
No (59)
- - - - 1758
[offset 60] 0x6D
(109)
1 to 4
0x0A (10)
- - - - 9010 uint
R
[CUrr]]
[oPEr]]
Current Menu Note: To use the current sensing feature, Time Base (Setup
Page, Output Menu) must be set to 0 .7 seconds or more .
[`C;hi]
[ C.hi] Current (1 to 4)
High Set Point
Set the current value
that will trigger a high
heater error state.
-1,999.000 to 9,999.000 50.0 1394
[offset 50] 0x73
(115)
1 to 4
8
- - - - 15008 float
RWES
[`C;Lo]
[ C.Lo] Current (1 to 4)
Low Set Point
Set the current value
that will trigger a low
heater error state.
-1,999.000 to 9,999.000 0.0 1396
[offset 50] 0x73
(115)
1 to 4
9
- - - - 15009 float
RWES
[`CU;r]
[ CU.r] Sensed Current (1 to 4)
Read
View the most recent
current value moni-
tored by the current
transformer.
-1,999.000 to 9,999.000 - - - - 1380
[offset 50] 0x73
(115)
1 to 4
1
- - - - 15001 float
R
No Dis-
play
Ammeter Current (1
to 4)
Read
RMS current value
monitored by the cur-
rent transformer.
0 to 9,999.00 - - - - 1392
[offset 50] 0x73
(115)
1 to 4
7
- - - - 15007 float
R
[`C;Er]
[ C.Er] Current (1 to 4)
Error
View the cause of the
most recent load fault.
[nonE] None (61)
[Shrt] Shorted (127)
[open] Open (65)
- - - - 1382
[offset 50] 0x73
(115)
1 to 4
2
- - - - 15002 uint
R
Note:
Some values will be rounded off to fit in the four-character display . Full values can be
read with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0
and above .
R: Read
W: Write
E: EEPROM
S: User Set
