Watlow EZ-ZONE RMC - Manual (Page 120)

Watlow EZ-ZONE ® RMC Module • 117 • Chapter 4 Setup Page
RMC Module • Setup Page
Dis-
play
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[GSd4]
[gSd4]
Profile
Guaranteed Soak De-
viation 4
Set the value of the
deviation band that will
be used in all profile
step types. The process
value for control loop 4
must enter the deviation
band before the step can
proceed. .
0.0 to 9,999.000°F or units
0.0 to 5,555.000°C 10.0°F or
units
6.0°C
5364 0x7A
(122)
1
0x2B (43)
- - - - 22043 float
RWE
[CM;E]
[CM.E]
Profile
Control Mode Enable
Use to allow the loops
control mode to be
programmed in profile
steps.
[`oFF] Off (62)
[``on] On (63)
Off 5356 0x7A
(122)
1
0x27 (39)
- - - - 22039 uint
RWE
[W;M]
[W.M]
Profile
Wait for Mode
Use to determine how
the wait-for conditions
must be satisfied:
• Complete requires
that all of the condi-
tions must be true at
the same time.
• Once requires that
all of the conditions
were true at some
time during the wait
period.
[Once] Once (1583)
[CPLt] Complete (18)
Complete 5358 0x7A
(122)
1
0x28 (40)
- - - - 22040 uint
RWE
Note:
Some values will be rounded off to fit in the four-character display .
Full values can be read with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E: EEPROM
S: User Set
