Watlow EZ-ZONE
®
RMC Module
•
77
•
Chapter 4 Setup Page
RMC Module • Setup Page
Dis-
play
Parameter Name
Description
Range
Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[A;tSP]
[A.tSP}
Control Loop (1 to 4)
Autotune Set Point **
Set the set point that
the autotune will use,
as a percentage of the
current set point.
50.0 to 200.0%
90.0
2258
[offset 70]
0x97
(151)
1 to 4
0x14 (20)
- - - -
8025
float
RWES
[t;Agr]
[t.Agr]
Control Loop (1 to 4)
Autotune Aggressive-
ness
Select the aggressive-
ness of the autotuning
calculations.
[Undr]
Under damped (99)
[Crit]
Critical damped (21)
[OuEr]
Over damped (69)
Critical
2256
[offset 70]
0x97 (151)
1 to 4
0x13 (19)
- - - -
8024
uint
RWES
[`p;dl]
[ P.dL]
Control Loop (1 to 4)
Peltier Delay
Set a value that will
cause a delay when
switching from heat PID
mode to cool PID mode.
0.0 to 5.0 seconds
0.0
2274
[offset 70]
0x97 (151)
1 to 4
0x1C (28)
- - - -
8051
float
RWES
[`r;En]
[ r.En]
Control Loop (1 to 4)
Remote Set Point En-
able
Set whether this loop
will use a remote set
point.
[``no]
No (59)
[`YES}
Yes (106)
No
2540
[offset 80]
0x6B
(107)
1 to 4
0x15 (21)
48
7021
uint
RWES
[SFn;b]
[SFn.b]
Control Loop (1 to 4)
Source Function B
Set the function that
will provide the remote
set point.
[nonE]
None (61)
[``Ai]
Analog Input (142)
[CUrr]
Current (22)
[`C;Pr]
Cool Power, Control
Loop (161)
[`h;Pr]
Heat Power, Control
Loop (160)
[PWr]
Power, Control Loop (73)
[`Lnr]
Linearization (238)
[MAt]
Math (240)
[``Pu]
Process Value (241)
[`SP;C]
Set Point Closed, Con-
trol Loop (242)
[`SP;o]
Set Point Open, Control
Loop (243)
[`uAr]
Variable (245)
None
2544
[offset 80]
0x6B
(107)
1 to 4
0x17 (23)
- - - -
7023
uint
RWES
[`Si;B]
[ Si.b]
Control Loop (1 to 4)
Source Instance B
Set the instance of the
function selected above.
1 to 250
1
2546
[offset 80]
0x6B
(107)
1 to 4
0x18 (24)
- - - -
7024
uint
RWES
[`S2;b]
[ SZ.b]
Control Loop (1 to 4)
Source Zone B
Set the zone of the func-
tion selected above.
0 to 16
0
2550
[offset 80]
0x6B
(107)
1 to 4
0x1A (26)
- - - -
7026
uint
RWES
Note:
Some values will be rounded off to fit in the four-character display .
Full values can be read with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E:
EEPROM
S:
User Set
