Watlow EZ-ZONE RMC User Manual
Page 139
Watlow EZ-ZONE
®
RMC Module
•
136
•
Chapter 5 Profiling Page
RMC Module •
Profile Page
Display
Parameter Name
Description
Range
Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data Type
& Read/
Write
[Min]
[Min]
Subroutine Step (1 to
150)
Minutes
If step type is Time,
enter time over which
set point changes. If
Soak or State Step,
enter time to maintain
this step. If step type
is Wait for Time, enter
time to wait on.
0 to 59
0
30460
[offset 86]
0x69
(105)
1 to (150)
0xB (11)
- - - -
5011
uint
RWE
[~SEC]
[ SEC]
Subroutine Step (1 to
150)
Seconds
If step type is Time,
enter time over which
set point changes. If
Soak or State Step,
enter time to maintain
this step. If step type
is Wait for Time, enter
time to wait on.
0 to 59
0
30462
[offset 86]
0x69
(105)
1 to (150)
0xC (12)
- - - -
5012
uint
RWE
[rate]
[rAtE]
Subroutine Step (1 to
150)
Rate
If step type is Rate,
select the rate for
ramping in degrees or
units per minute.
0 to 9,999.000°F or units
per minute
0 to 5,555.000°C per min-
ute
0.0
30464
[offset 86]
0x69
(105)
1 to (150)
0xD (13)
- - - -
5013
float
RWE
[`P;E1]
[P.E1]
Subroutine Step (1 to
150)
Step Wait For Pro-
cess Enable 1
If step type is Wait
for Process or Event,
select whether process
value must be Less
Than or Greater Than
the value of Wait for
Process to satisfy the
wait-for condition.
[`oFF]
Off (62)
[``L;t]
Less Than (1436)
[``g;t]
Greater Than
(1435)
Off
30490
[offset 86]
0x69
(105)
1 to (150)
0x1A (26)
- - - -
5026
uint
RWE
[W;P1]
[W.P1]
Subroutine Step (1 to
150)
Wait For Process 1
Enter a value that
must be satisfied
which is specified by
Source E in Profile
Setup.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
0.0°F or
units
-18.0°C
30498
[offset 86]
0x69
(105)
1 to (150)
0x1E (30)
- - - -
5030
float
RWE
Note: Some values will be rounded off to fit in the four-character display . Full values
can be read with other interfaces .
If there is only one instance of a menu, no submenus will appear .
R: Read
W: Write
E: EEPROM
S: User Set
