Watlow EZ-ZONE ® RMC Module • 123 • Chapter 4 Setup Page
RMC Module • Setup Page
Dis-
play
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[`Si;G]
[ Si.g] Profile
Source Instance G
Set the instance of the
function selected above.
1 to 250 1 5402 0x7A
(122)
1
0x3E (62)
- - - - 22062 uint
RWE
[`S2;G]
[ SZ.g] Profile
Zone Source G
Set the zone of the func-
tion selected above.
0 to 16 0 5410 0x7A
(122)
1
0x42 (66)
- - - - 22066 uint
RWE
[SFn;h]
[SFn.h] Profile
Source Function H
Set the type of function
that will be used for
this source. Source will
be used in profile step
type "Wait for Process
or Event" as "Wait For
Process 4"
[nonE] None (61)
[``Ai] Analog Input (142)
[CUrr] Current (22)
[`C;Pr] Cool Power, Control
Loop (161)
[`h;Pr] Heat Power, Control
Loop (160)
[PWr] Power, Control Loop (73)
[`Lnr] Linearization (238)
[MAt] Math (240)
[``Pu] Process Value (241)
[`SP;C] Set Point Closed, Con-
trol Loop (242)
[`SP;o] Set Point Open, Control
Loop (243)
[`uAr] Variable (245)
None 5396 0x7A
(122)
1
0x3B (59)
- - - - 22059 uint
RWE
[`Si;h]
[ Si.h] Profile
Source Instance H
Set the instance of the
function selected above.
1 to 250 1 5404 0x7A
(122)
1
0x3F (63)
- - - - 22063 uint
RWE
[`S2;h]
[ SZ.h] Profile
Source Zone H
Set the zone of the func-
tion selected above.
0 to 16 0 5412 0x7A
(122)
1
0x43 (67)
- - - - 22067 uint
RWE
[CoM]
[`SEt]
Communications Menu
[bAUd]
[bAUd] Communications
Baud Rate
Set the speed of this con-
troller's communications
to match the speed of
the serial network.
Note:
This applies if 13 th
digit in part number is
equal to one.
9,600 (188)
19,200 (189)
38,400 (190) 9,600 2824 0x96 (150)
1
3
- - - - 17002 uint
RWE
Note:
Some values will be rounded off to fit in the four-character display .
Full values can be read with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E: EEPROM
S: User Set
