Watlow EZ-ZONE ® RMC Module • 135 • Chapter 5 Profiling Page
RMC Module • Profile Page
Display
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data Type
& Read/
Write
[C;M3]
[C.M3] Subroutine Step (1 to
150)
Control Mode Loop 3
Set the control mode
for this loop.
[AUto] Auto (10)
[`oFF] Off (62)
[MAn] Manual (54)
Auto 30446
[offset 86]
0x69
(105)
1 to (150)
4
- - - - 5004 uint
RWE
[C;M4]
[C.M4] Subroutine Step (1 to
150)
Control Mode Loop 4
Set the control mode
for this loop.
[AUto] Auto (10)
[`oFF] Off (62)
[MAn] Manual (54)
Auto 30448
[offset 86]
0x69
(105)
1 to (150)
5
- - - - 5005 uint
RWE
[t;SP1]
[t.SP1] Subroutine Step (1 to
150)
Target Set Point
Loop 1
If step type is Time or
State - enter set point
for this loop. If Rate
step, enter set point
for loops 1, 2, 3 and 4.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
0.0 30450
[offset 86]
0x69
(105)
1 to (150)
6
- - - - 5006 float
RWE
[t;SP2]
[t.SP2] Subroutine Step (1 to
150)
Target Set Point
Loop 2
If step type is Time or
State - enter set point
for this loop.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
0.0 30452
[offset 86]
0x69
(105)
1 to (150)
7
- - - - 5007 float
RWE
[t;SP3]
[t.SP3] Subroutine Step (1 to
150)
Target Set Point
Loop 3
If step type is Time or
State - enter set point
for this loop.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
0.0 30454
[offset 86]
0x69
(105)
1 to (150)
8
- - - - 5008 float
[t;SP4]
[t.SP4] Subroutine Step (1 to
150)
Target Set Point
Loop 4
If step type is Time or
State - enter set point
for this loop.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
0.0 30456
[offset 86]
0x69
(105)
1 to (150)
9
- - - - 5009 float
RWE
[hoUr]
[hoUr] Subroutine Step (1 to
150)
Hours
If step type is Time,
enter time over which
set point changes. If
Soak or State Step,
enter time to maintain
this step. If step type
is Wait for Time, enter
time to wait on.
0 to 23 0 30458
[offset 86]
0x69
(105)
1 to (150)
0xA (10)
- - - - 5010 uint
RWE
Note: Some values will be rounded off to fit in the four-character display . Full values
can be read with other interfaces .
If there is only one instance of a menu, no submenus will appear .
R: Read
W: Write
E: EEPROM
S: User Set
