Watlow EZ-ZONE RMC - Manual (Page 142)

Watlow EZ-ZONE ® RMC Module • 139 • Chapter 5 Profiling Page
RMC Module • Profile Page
Display
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data Type
& Read/
Write
[gSE2]
[gSE2] Subroutine Step (1 to
150)
Guaranteed Soak
Enable 2
Select if profile should
pause while process 2
deviates from devia-
tion band.
[`oFF] Off (62)
[``on] On (63)
Off 30512
[offset 86]
0x69
(105)
1 to (150)
0x25 (37)
- - - - 5037 uint
RWE
[gSE3]
[gSE3] Subroutine Step (1 to
150)
Guaranteed Soak
Enable 3
Select if profile should
pause while process 3
deviates from devia-
tion band.
[`oFF] Off (62)
[``on] On (63)
Off 30514
[offset 86]
0x69
(105)
1 to (150)
0x26 (38)
- - - - 5038 uint
RWE
[gSE4]
[gSE4] Subroutine Step (1 to
150)
Guaranteed Soak
Enable 4
Select if profile should
pause while process 4
deviates from devia-
tion band.
[`oFF] Off (62)
[``on] On (63)
Off 30516
[offset 86]
0x69
(105)
1 to (150)
0x27 (39)
- - - - 5039 uint
RWE
[Ent1]
[Ent1] Subroutine Step (1 to
150)
Event 1
Select whether output
programmed as Pro-
file Event Out A is on,
unchanged or off dur-
ing this step.
[Ucgd] Unchanged (1557)
[`oFF] Off (62)
[``on] On (63)
Un-
changed
30466
[offset 86]
0x69
(105)
1 to (150)
0xE (14)
- - - - 5014 uint
RWE
[Ent2]
[Ent2] Subroutine Step (1 to
150)
Event 2
Select whether output
programmed as Pro-
file Event Out B is on,
unchanged or off dur-
ing this step.
[Ucgd] Unchanged (1557)
[`oFF] Off (62)
[``on] On (63)
Un-
changed
30468
[offset 86]
0x69
(105)
1 to (150)
0xF (15)
- - - - 5015 uint
RWE
[Ent3]
[Ent3] Subroutine Step (1 to
150)
Event 3
Select whether output
programmed as Pro-
file Event Out C is on,
unchanged or off dur-
ing this step.
[Ucgd] Unchanged (1557)
[`oFF] Off (62)
[``on] On (63)
Un-
changed
30470
[offset 86]
0x69
(105)
1 to (150)
0x10 (16)
- - - - 5016 uint
RWE
[Ent4]
[Ent4] Subroutine Step (1 to
150)
Event 4
Select whether output
programmed as Pro-
file Event Out D is on,
unchanged or off dur-
ing this step.
[Ucgd] Unchanged (1557)
[`oFF] Off (62)
[``on] On (63)
Un-
changed
30472
[offset 86]
0x69
(105)
1 to (150)
0x11 (17)
- - - - 5017 uint
RWE
Note: Some values will be rounded off to fit in the four-character display . Full values
can be read with other interfaces .
If there is only one instance of a menu, no submenus will appear .
R: Read
W: Write
E: EEPROM
S: User Set
