Watlow EZ-ZONE ® RMC Module • 75 • Chapter 4 Setup Page
RMC Module • Setup Page
Dis-
play
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[LooP]
[`Set]]
Control Loop Menu
[SFn;A]
[SFn.A] Control Loop (1 to 4)
Source Function A
Set the type of function
that will be used for this
source.
[``Ai] Analog Input (142)
[``Pu] Process Value (241)
Analog
Input
2276
[offset 70]
0x97 (151)
1 to 4
0x1D (29)
- - - - 8050 RWE
[`is;a]
[ iS.A] Control Loop (1 to 4)
Source Instance A
Source Instance A fol-
lows the Control Loop
and is not changeable
1 to 250 - - - - - - - - - - - - - - - - 8021 R
[`h;Ag]
[ h.Ag] Control Loop (1 to 4)
Heat Algorithm
Set the heat control
method.
[`oFF] Off (62)
[`Pid] PID (71)
[on;of] On-Off (64)
PID 2224
[offset 70]
0x97 (151)
1 to 4
3
72 8003 uint
RWES
[`C;Ag]
[ C.Ag] Control Loop (1 to 4)
Cool Algorithm
Set the cool control
method.
[`oFF] Off (62)
[`Pid] PID (71)
[on;of] On-Off (64)
Off 2226
[offset 70]
0x97 (151)
1 to 4
4
73 8004 uint
RWES
[`C;Cr]
[ C.Cr] Control Loop (1 to 4)
Cool Output Curve
Select a cool output
curve to change the
responsiveness of the
system.
[`oFF] Off (62)
[`Cr;A] Non-linear Curve 1 (214)
[`Cr;b] Non-linear Curve 2 (215)
Off 2228
[offset 70]
0x97 (151)
1 to 4
5
- - - - 8038 uint
RWES
[`h;Pb]
[ h.Pb] Control Loop (1 to 4)
Heat Proportional
Band **
Set the PID propor-
tional band for the heat
outputs.
0.001 to 9,999.000°F or units
0.001 to 5,555.000°C
25.0°F or
units
14.0°C
2230
[offset 70]
0x97
(151)
1 to 4
6
65 8009 float
RWES
[`h;hy]
[ h.hy] Control Loop (1 to 4)
Heat Hysteresis **
Set the control switch-
ing hysteresis for on-off
control. This deter-
mines how far into the
“on” region the process
value needs to move
before the output turns
on.
0.001 to 9,999.000°F or units
0.001 to 5,555.000°C
3.0°F or
units
2.0°C
2240
[offset 70]
0x97
(151)
1 to 4
0xB (11)
66 8010 float
RWES
[`C;Pb]
[ C.Pb] Control Loop (1 to 4)
Cool Proportional
Band **
Set the PID propor-
tional band for the cool
outputs.
0.001 to 9,999.000°F or units
0.001 to 5,555.000°C
25.0°F or
units
14.0°C
2232
[offset 70]
0x97
(151)
1 to 4
7
67 8012 float
RWES
Note:
Some values will be rounded off to fit in the four-character display .
Full values can be read with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E: EEPROM
S: User Set
