Watlow EZ-ZONE ® RMC Module • 141 • Chapter 5 Profiling Page
Display Step Type
Description
Parameters in Step Type
[UStP]
[UStP]
Step Types
Unused Step
This is an empty step that can be used to plan for future
steps to be inserted or temporarily deactivate a step in a
profile. Change step type back when the step should be ac-
tive again.
- - - -
[``ti]
[ ti]
Step Types
Time
If Ramping Type in Setup Profile is set for Time, control
loop 1 to 4 may be part of the profile and all enabled control
loops follow independent set points over the specified time.
The state of up to 8 event outputs may be set or maintained.
[CM;1] Control Mode Loop 1
[CM;2] Control Mode Loop 2
[CM;3] Control Mode Loop 3
[CM;4] Control Mode Loop 4
[tg;S1] Target Set Point Loop 1
[tg;S2] Target Set Point Loop 2
[tg;S3] Target Set Point Loop 3
[tg;S4] Target Set Point Loop 4
[hoUr] Hours
[Min] Minutes
[`SEC] Seconds
[gSE1] Guaranteed Soak Enable 1
[gSE2] Guaranteed Soak Enable 2
[gSE3] Guaranteed Soak Enable 3
[gSE4] Guaranteed Soak Enable 4
[Ent1] Event 1
[Ent2] Event 2
[Ent3] Event 3
[Ent4] Event 4
[Ent5] Event 5
[Ent6] Event 6
[Ent7] Event 7
[Ent8] Event 8
[rAtE]
[rAtE]
Step Types
Rate
If Ramping Type in Setup Profile is set for Rate, control loop
1 must be part of the profile and all other enabled control
loops follow the same set point and rate in degrees or units
per minute. Ensure all control loops have the same units of
measure. The state of up to 8 event outputs may be set or
maintained.
[CM;1] Control Mode Loop 1
[CM;2] Control Mode Loop 2
[CM;3] Control Mode Loop 3
[CM;4] Control Mode Loop 4
[tg;S1] Target Set Point Loop 1
[gSE1] Guaranteed Soak Enable 1
[gSE2] Guaranteed Soak Enable 2
[gSE3] Guaranteed Soak Enable 3
[gSE4] Guaranteed Soak Enable 4
[rAtE] Rate
[Ent1] Event 1
[Ent2] Event 2
[Ent3] Event 3
[Ent4] Event 4
[Ent5] Event 5
[Ent6] Event 6
[Ent7] Event 7
[Ent8] Event 8
