Watlow EZ-ZONE ® RMC Module • 192 • Chapter 7 Features
[r;tyP] Ramping Type : Rate, Time
[P;tyP] Profile Type : Set Point, Process
[`gSE] Guaranteed Soak Enable : Off, On
[gSd1] [gSd2] [gSd3] [gSd4] Guaranteed Soak Deviation 1 to 4 : 0 to 9,999.000
[CM;E] Control Mode Enable : Off, On
[W;M] Wait for Mode : Once, Complete
[`Si;A] Source Instance A : 1 to 250
[`Si;b] Source Instance B : 1 to 250
[`Si;C] Source Instance C : 1 to 250
[`Si;d] Source Instance D : 1 to 250
[`Si;E] Source Instance E : 1 to 250
[`Si;F] Source Instance F : 1 to 250
[`Si;g] Source Instance G : 1 to 250
[`Si;h] Source Instance H : 1 to 250
[`S2;A] Source Zone A : 0 to 16
[`S2;b] Source Zone B : 0 to 16
[`S2;C] Source Zone C : 0 to 16
[`S2;d] Source Zone D : 0 to 16
[`S2;E] Source Zone E : 0 to 16
[`S2;F] Source Zone F : 0 to 16
[`S2;g] Source Zone G : 0 to 16
[`S2;h] Source Zone H : 0 to 16
[`Pro] Profile Menu
[`SEt] Setup Page
[sfn;h] Source Function H (Wait Analog 4) : None, Analog Input, Current, Cool Power, Heat
Power, Power, Linearization, Math, Process Value, Set Point Closed, Set Point Open,
Variable
[sfn;g] Source Function G (Wait Analog 3) : None, Analog Input, Current, Cool Power, Heat
Power, Power, Linearization, Math, Process Value, Set Point Closed, Set Point Open,
Variable
[sfn;f] Source Function F (Wait Analog 2) : None, Analog Input, Current, Cool Power, Heat
Power, Power, Linearization, Math, Process Value, Set Point Closed, Set Point Open,
Variable
[sfn;e] Source Function E (Wait Analog 1) : None, Analog Input, Current, Cool Power, Heat
Power, Power, Linearization, Math, Process Value, Set Point Closed, Set Point Open,
Variable
[sfn;d] Source Function D (Wait Event Input 4) : None, Alarm, Compare, Counter, Digital
I/O, Profile Event Out A to H, Function Key, Logic, Timer, Variable
[sfn;C] Source Function C (Wait Event Input 3) : None, Alarm, Compare, Counter, Digital
I/O, Profile Event Out A to H, Function Key, Logic, Timer, Variable
[sfn;b] Source Function B (Wait Event Input 2) : None, Alarm, Compare, Counter, Digital
I/O, Profile Event Out A to H, Function Key, Logic, Timer, Variable
[sfn;a] Source Function A (Wait Event Input 1) : None, Alarm, Compare, Counter, Digital
I/O, Profile Event Out A to H, Function Key, Logic, Timer, Variable
