Watlow EZ-ZONE ® RMC Module • 41 • Chapter 3 Operations Page
RMC Module • Operations Page
Display
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[``Ai]
[oPEr]
Analog Input Menu
``Ain]
[ Ain] Analog Input (1 to 4)
Value
View the process value.
Note:
Ensure that the Er-
ror Status (below)
indicates no error (61)
when reading this
value using a field bus
protocol. If an error
exists, the last known
value prior to the er-
ror occurring will be
returned.
-1,999.000 to 9,999.000°F or
units
-1,128.000 to 5,537.000°C
- - - - 360
[offset 90]
0x68 (104)
1 to 4
1
0 4001 float
R
[`i;Er]
[ i.Er] Analog Input (1 to 4)
Error Status
View the cause of the
most recent error. If
the [Attn] message is
[Er;i1]
or [Er;i2], this
parameter will display
the cause of the input
error.
[nonE] None (61)
[OPEn] Open (65)
[Shrt] Shorted (127)
[`E;M] Measurement Error
(140)
[E;CAL] Bad Calibration Data
(139)
[Er;Ab] Ambient Error (9)
[E;;Rtd] RTD Error (141)
[FAiL] Fail (32)
- - - - 362
[offset 90]
0x68 (104)
1 to 4
2
1 4002 uint
R
[`i;Ca]
[ i.CA] Analog Input (1 to 4)
Calibration Offset
Offset the input reading
to compensate for lead
wire resistance or other
factors that cause the in-
put reading to vary from
the actual process value.
-1,999.000 to 9,999.000°F or
units
-1,110.555 to 5,555.000°C
0.0 382
[offset 90]
0x68 (104)
1 to 4
0xC (12)
2 4012 float
RWES
No Dis-
play
Analog Input (1 to 4)
Clear Latched Input
Error
Clear latched input
when input error condi-
tion no longer exists.
Clear Latch (1221) - - - - 416
[offset 90]
0x68 (104)
1 to 4
0x1D (29)
- - - - 4029 uint
RW
[``Pu]
[oPEr]]
Process Value Menu
[`Su;A]
[ Su.A] Process Value (1 to 4)
Source Value A
View the value of Source
A.
-1,999.000 to 9,999.000°F or
units
-1,128.000 to 5,537.000°C
- - - - 3430
[offset 70]
0x7E (126)
1 to 4
0x10 (16)
- - - - 26016 float
R
[`Su;b]
[ Su.b] Process Value (1 to 4)
Source Value B
View the value of Source
B.
-1,999.000 to 9,999.000°F or
units
-1,128.000 to 5,537.000°C
- - - - 3432
[offset 70]
0x7E (126)
1 to 4
0x11 (17)
- - - - 26017 float
R
Note:
Some values will be rounded off to fit in the four-character display . Full values can be
read with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0
and above .
R: Read
W: Write
E: EEPROM
S: User Set
