Chapter 4 Setup Page
RMC Module • Setup Page
Dis-
play
Parameter Name
Description
Range
Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[SFn;E]
[SFn.E]
Math (1 to 8)
Source Function E
Set the type of function
that will be used for this
source.
[none]
None (61)
[ALM]
Alarm (6)
[`CPE]
Compare (230)
[`Ctr]
Counter (231)
[`dio]
Digital I/O (1142)
[Ent;A]
Profile Event Out A
(233)
[Ent;b]
Profile Event Out B
(234)
[Ent;C]
Profile Event Out C
(235)
[Ent;d]
Profile Event Out D
(236)
[Ent;E]
Profile Event Out E
(247)
[Ent;F]
Profile Event Out F
(248)
[Ent;g]
Profile Event Out G
(249)
[Ent;h]
Profile Event Out H
(250)
[`FUn]
Function Key (1001)
[`lgC]
Logic (239)
[tMr]
Timer (244)
[`uAr]
Variable (245))
None
2848
[offset 70]
0x7D
(125)
1 to 8
5
- - - -
25005
uint
RWES
[`Si;E]
[ Si.E]
Math (1 to 8)
Source Instance E
Set the instance of the
function selected above.
1 to 250
1
2858
[offset 70]
0x7D
(125)
1 to 8
0xA (10)
- - - -
25010
uint
RWES
[`s2;E]
[ SZ.E]
Math (1 to 8)
Source Zone E
Set the zone of the func-
tion selected above.
0 to 16
0
2868
[offset 70]
0x7D
(125)
1 to 8
0xF (15)
- - - -
25015
uint
RWES
[`S;Lo]
[ S.Lo]
Math (1 to 8)
Scale Low
If Math function is set to
Process Scale, this will
scale Source A low value
to Range Low setting.
-1,999.000 to 9,999.000
0.0
2886
[offset 70]
0x7D
(125)
1 to 8
0x18 (24)
129
25024
float
RWES
[`S;hi]
[ S.hi]
Math (1 to 8)
Scale High
If Math function is set
to Process Scale, this
will scale Source A high
value to Range High
setting.
-1,999.000 to 9,999.000
1.0
2888
[offset 70]
0x7D
(125)
1 to 8
0x19 (25)
130
25025
float
RWES
Note:
Some values will be rounded off to fit in the four-character display .
Full values can be read with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E:
EEPROM
S:
User Set
