Watlow EZ-ZONE ® RMC Module • 209 • Chapter 7 Features
Security Function
Note:
Set on a Zone by Zone basis affecting any access using
Standard Bus communications. Does not affect field
protocols.. This is independent of the RUI Security
Setting.
If the Password is enabled, the user must enter the Pass-
word to get to menus that have been blocked due to lock
level settings. Rolling passwords require a new password
each time the power has been cycled to the controller. It
will be different for every controller. The administrator
password is required to change the security settings even
if the user enters their password to override the security
settings.
Security Function Block - Overview
Instances - 1 per RMC
[LoC;o]
Operations Page : 1 to 3
[r;LoC]
Read Lock : 1 to 5
[S;LoC]
Write Security: 1 to 5
[LoC;P]
Profiling Page : 1 to 3
[PAS;E]
Password Enable : Off, On
[LoC;L]
Locked Access Level : 1 to 5
[roL;L]
Rolling Password : Off, On
[PAS;u]
User Password : 10 to 999
[PAS;A]
Administrator Password : 10 to 999
[CodE]
Public Key : xxx
[PASS]
Password : xxx
Write Security
Loc
ked
Access Level
Rolling P
assword
User P
assword
Administrator P
assword
Public K
ey
Password
Profiling P
age
Read Loc
k
Operations P
age
[LoC]
Lock Menu
[FAct]
Factory Page
[ULoC]
Unlock Menu
[FAct]
Factory Page
Special Output Function
This function is used to configure outputs when used
with compressors, motorized valves or sequencers
An error (1 - 4), when read, can indicate any of the follow-
ing: None, Open, Shorted, Measurement Error, Bad Cal
Data, Ambient Error, RTD Error, Fail, Math Error, Not
Sourced, Stale
Special Output
Overview
Instances - 4 per RMC
[`S2;A] Source Zone A : 0 to 16
[`S2;b] Source Zone B : 0 to 16
[Pon;A] Power On Level 1 : -100.0 to 100.0 %
[Pon;b] Power On Level 2 : -100.0 to 100.0 %
[PoF;A] Power Off Level 1 : -100.0 to 100.0 %
[PoF;b] Power Off Level 2 : -100.0 to 100.0 %
[`on;t] On Time : 0 to 9,999 seconds
[`oF;t] Off Time : 0 to 9,999 seconds
[``t;t] Valve Travel Time : 10 to 9,999 seconds
[``db] Dead Band : 1.0 to 100.0 %
[`o;S1] Output 1 Size : 0 to 9,999
[`o;S2] Output 2 Size : 0 to 9,999
[`o;S3] Output 3 Size : 0 to 9,999
[`o;S4] Output 4 Size : 0 to 9,999
[`t;dL] Time Delay : 0 to 9,999 seconds
[`ot;o] Output Order : Linear, Progressive
[`Si;A] Source Instance A : 1 to 250
[`Si;b] Source Instance B : 1 to 250
Source Function A
Source Instance A
Source Zone A
Source Error A
Source Function B
Source Instance B
Source Zone B
Source Error B
Power On Level 1 Power On Level 2 Power Off Level 1 Power Off Level 2
Minimum On
Time
Minimum Off
Time
Valve
Tra
vel
Time
Dead Band
Output 1 Size Output 2 Size Output 3 Size Output 4 Size
Time Dela
y
Output Order
Function
[`SoF] Special Output Function Menu
[`SEt] Setup Page
Output Value 4
Output Value 3
Output Value 2
Output Value 1
Error 1 to 4
Source Value A
Source Value B
[Su;A] Source Value A : -1,999.000 to 9,999.000
[Su;b] Source Value B : -1,999.000 to 9,999.000
[o;u1] Output Value 1 : -1,999.000 to 9,999.000 %
[o;u2] Output Value 2 : -1,999.000 to 9,999.000 %
[o;u3] Output Value 3 : -1,999.000 to 9,999.000 %
[o;u4] Output Value 4 : -1,999.000 to 9,999.000 %
[`SoF] Special Output Function Menu
[oPEr] Operation Page
[sfn;a] Source Function A : None, Analog Input, Cool Power,
Heat Power, Power, Linearization, Math, Process
Value, Special Function Output 1, Variable
[sfn;b] Source Function B : None, Cool Power, Heat Power,
Power, Linearization, Math, Variable
[``fn] Function : Off, Compressor, Motorized Valve,
Sequencer
