Chapter 4 Setup Page
RMC Module • Setup Page
Dis-
play
Parameter Name
Description
Range
Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[a;Clr]
[A.CLr]
Alarm (1 to 8)
Alarm Clear Request
**
Write to this register to
clear an alarm
0
- - - -
1764
[offset
60]
0x6D
(109)
1 to 8
0xD (13)
32
9013
uint
W
[A;sir]
[A.Sir]
Alarm (1 to 8)
Alarm Silence Re-
quest **
Write to this register to
silence an alarm
0
- - - -
1766
[offset
60]
0x6D
(109)
1 to 8
0xE (14)
33
9014
uint
W
[`a;st]
[ A.St]
Alarm (1 to 8)
Alarm State **
Current state of alarm
Startup (88)
None (61)
Blocked (12)
Alarm low (8)
Alarm high (7)
Error (28)
- - - -
1756
[offset
60]
0x6D
(109)
1 to 8
9
- - - -
9009
uint
R
[CUrr]
[`Set]
Current Menu
[`C;Sd]
[ C.Sd]
Current (1 to 4)
Sides
Use Current Sides to
select which side of the
current to monitor.
[`oFF]
Off (62)
[high]
High (37)
[low]
Low (53)
[both]
Both (13)
off
1388
[offset 50]
0x73 (115)
1 to 4
5
145
15005
uint
RWES
[`C;Ur]
[ C.Ur]
Current (1 to 4)
Read Enable
Use Current Read En-
able to display solid-
state relay (SSR) failure
and heater failure mes-
sages on the RUI (re-
mote user interface).
[``no]
No (59)
[`yes]
Yes (106)
no
1386
[offset 50]
0x73 (115)
1 to 4
4
146
15004
uint
RWES
[`C;dt]
[ C.dt]
Current (1 to 4)
Detection Threshold
Current Detection
Threshold is for factory
use only.
3 to 59
9
1402
[offset 50]
0x73 (115)
1 to 4
0xC (12)
147
15012
uint
RWES
[`C;SC]
[ C.SC]
Current (1 to 4)
Scaling
Use Input Current Scal-
ing to adjust scaling to
match the transformer's
high range, in amperes.
0 to 9,999.000
50.0
1422
[offset 50]
0x73 (115)
1 to 4
0x16 (22)
148
15022
float
RWES
[C;;oFs]
[C.oFS]
Current (1 to 4)
Heater Offset
Heater Current Offset
is used to calibrate the
current reading with an
offset value.
-9,999.000 to 9,999.000
0.0
1400
[offset 50]
0x73 (115)
1 to 4
0xB (11)
149
15011
float
RWES
Note:
Some values will be rounded off to fit in the four-character display .
Full values can be read with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E:
EEPROM
S:
User Set
