Watlow EZ-ZONE ® RMC Module • 119 • Chapter 4 Setup Page
RMC Module • Setup Page
Dis-
play
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[SFn;b]
[SFn.b] Profile
Source Function B
Set the type of function
that will be used for
this source. Source will
be used in profile step
type "Wait for Process or
Event" as "Event 1"
[none] None (61)
[ALM] Alarm (6)
[`CPE] Compare (230)
[`Ctr] Counter (231)
[`dio] Digital I/O (1142)
[Ent;A] Profile Event Out A
(233)
[Ent;b] Profile Event Out B
(234)
[Ent;C] Profile Event Out C
(235)
[Ent;d] Profile Event Out D
(236)
[Ent;E] Profile Event Out E
(247)
[Ent;F] Profile Event Out F
(248)
[Ent;g] Profile Event Out G
(249)
[Ent;h] Profile Event Out H
(250)
[`FUn] Function Key (1001)
[`lgC] Logic (239)
[tMr] Timer (244)
[`uAr] Variable (245))
None 5324 0x7A
(122)
1
0x17 (23)
- - - - 22023 uint
RWE
[`Si;B]
[ Si.b] Profile
Source Instance B
Set the instance of the
function selected above.
1 to 250 1 5332 0x7A
(122)
1
0x1B (27)
- - - - 22027 uint
RWE
[`S2;B]
[ SZ.b] Profile
Source Zone B
Set the zone of the func-
tion selected above.
0 to 16 0 5340 0x7A
(122)
1
0x1F (31)
- - - - 22031 uint
RWE
Note:
Some values will be rounded off to fit in the four-character display .
Full values can be read with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E: EEPROM
S: User Set
