Watlow EZ-ZONE ® RMC Module • 13 • Chapter 2 Install and Wire
Dimensions
Module Removal Clearance Straight Connectors
Module Removal Clearance Standard Connectors
As can be seen below the dimensions of the RMC module will change slightly based on the type of connector
used.
147.07 mm
( 5.8 in )
101.60 mm
( 4.00 in )
44.45 mm
( 1.75 in )
51.56 mm
( 2.03 in )
75.08 mm
( 3.0 in )
165 mm
( 6.50 in )
Module Removal Displacement
Latch in open position
116.08 mm
( 4.57 in )
15 0
155 mm
( 6.10 )
116.08 mm
( 4.57 in )
101.60 mm
( 4.00 in )
44.45 mm
( 1.75 in )
51.56 mm
( 2.03 in )
75.08 mm
( 3.0 in )
15 °
173.90 mm
( 6.85 in )
Module Removal Displacement
Chapter 2: Install and Wire
2
