Watlow EZ-ZONE RMC User Manual
Page 133
Watlow EZ-ZONE
®
RMC Module
•
130
•
Chapter 5 Profiling Page
RMC Module •
Profile Page
Display
Parameter Name
Description
Range
Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data Type
& Read/
Write
[hoUr]
[hoUr]
Step (1 to 250)
Hours
If step type is Time,
enter time over which
set point changes. If
Soak or State Step,
enter time to maintain
this step.
0 to 99
0
5444
[offset 100]
0x79
(121)
1 to (250)
3
- - - -
21003
uint
RWE
[Min]
[Min]
Step (1 to 250)
Step Type Parameters
Minutes
If step type is Time,
enter time over which
set point changes. If
Soak or State Step,
enter time to maintain
this step.
0 to 59
0
5446
[offset 100]
0x79
(121)
1 to (250)
4
- - - -
21004
uint
RWE
[~SEC]
[ SEC]
Step (1 to 250)
Seconds
If step type is Time,
enter time over which
set point changes. If
Soak or State Step,
enter time to maintain
this step.
0 to 59
0
5448
[offset 100]
0x79
(121)
1 to (250)
5
- - - -
21005
uint
RWE
[rate]
[rAtE]
Step (1 to 250)
Rate
If step type is Rate,
select the rate for
ramping in degrees or
units per minute.
0 to 9,999.000°F or units
per minute
0 to 5,555.000°C per min-
ute
0.0
5450
[offset 100]
0x79
(121)
1 to (250)
6
- - - -
21006
float
RWE
[`P;E1]
[P.E1]
Step (1 to 250)
Step Wait For Pro-
cess Enable 1
If step type is Wait
for Process or Event,
select whether process
value must be Less
Than or Greater Than
the value of Wait for
Process to satisfy the
wait-for condition.
[`oFF]
Off (62)
[``L;t]
Less Than (1436)
[``g;t]
Greater Than
(1435)
Off
5510
[offset 100]
0x79
(121)
1 to (250)
0x24 (36)
- - - -
21036
uint
RWE
[W;P1]
[W.P1]
Step (1 to 250)
Wait For Process 1
Enter a value that
must be satisfied
which is specified by
Source E in Profile
Setup.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
0.0°F or
units
-18.0°C
5460
[offset 100]
0x79
(121)
1 to (250)
0xB (11)
- - - -
21011
float
RWE
[`P;E2]
[P.E2]
Step (1 to 250)
Step Wait For Pro-
cess Enable 2
If step type is Wait
for Process or Event,
select whether process
value must be Less
Than or Greater Than
the value of Wait for
Process to satisfy the
wait-for condition.
[`oFF]
Off (62)
[``L;t]
Less Than (1436)
[``g;t]
Greater Than
(1435)
Off
5512
[offset 100]
0x79
(121)
1 to (250)
0x25 (37)
- - - -
21037
uint
RWE
Note: Some values will be rounded off to fit in the four-character display . Full values
can be read with other interfaces .
If there is only one instance of a menu, no submenus will appear .
R: Read
W: Write
E: EEPROM
S: User Set
