Watlow EZ-ZONE ® RMC Module • 55 • Chapter 3 Operations Page
RMC Module • Operations Page
Display
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[P;Sta]
[oPEr]
Profile Status Menu * Some parameters in the Profile Status Menu can be changed for the currently running profile,
but should only be changed by knowledgeable personnel and with caution. Changing parameters
via the Profile Status Menu will not change the stored profile but will have an immediate impact
on the profile that is running.
Changes made to profile parameters in the Profiling Pages will be saved and will also have an
immediate impact on the running profile.
[P;Str]
[P.Str] Profile Status
Profile Start
1 to 25 1 5280 0x7A
(122)
1
1
204 22001 uint
W
[P;ACr]
[PACr] Profile Status
Action Request
[nonE] None (61)
[PAUS] Pause (146)
[rESU] Resume (147)
[`End] Terminate (148)
[ProF] Profile (77)
None 5300 0x7A
(122)
1
0xB (11)
205 22011 uint
W
[`StP]
[ StP] Profile Status
Active Step
View the currently run-
ning step.
0 to 250
0 (none)
- - - - 5286 0x7A
(122)
1
4
- - - - 22004 uint
R
[SUb;S]
[SUb.S] Profile Status
Active Subroutine
Step
View the currently run-
ning subroutine.
0 to 150
0 (none)
- - - - 0x7A
(122)
1
0x37 (55)
- - - - 22055 uint
R
[S;typ]
[S.typ] Profile Status
Active Step Type
View the currently run-
ning step type.
[UStP] Unused Step (50)
[``ti] Time (143)
[rAtE] Rate (81)
[SoAH] Soak (87)
[CLoC] Wait For Time
(1543)
[W;PE] Wait For Process or
Event (1542)
[Stat] State (1515)
[Subr] Subroutine Step
(1516)
[``JL] Jump Loop (116)
[`End] End (27)
- - - - 5304 0x7A
(122)
1
0xD (13)
- - - - 22013 uint
R
[t;SP1]
[tg.SP] Profile Status
*Target Set Point
Loop 1
View or change the
target set point of the
current step.
-1,999.000 to 9,999.000°F or
units
-1,128.000 to 5,537.000°C
0.0°F
or
units
-18.0°C
5302 0x7A
(122)
1
0xC (12)
- - - - 22012 float
RW
[t;SP2]
[tg.SP] Profile Status
*Target Set Point
Loop 2
View or change the
target set point of the
current step.
-1,999.000 to 9,999.000°F or
units
-1,128.000 to 5,537.000°C
0.0°F
or
units
-18.0°C
5374 0x7A
(122)
1
0x30 (48)
- - - - 22048 float
RW
Note:
Some values will be rounded off to fit in the four-character display . Full values can be
read with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0
and above .
R: Read
W: Write
E: EEPROM
S: User Set
