Watlow EZ-ZONE RMC - Manual (Page 114)

Watlow EZ-ZONE ® RMC Module • 111 • Chapter 4 Setup Page
RMC Module • Setup Page
Dis-
play
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[SFn;A]
[SFn.A] Special Output (1 to 4)
Source Function A
Set the type of function
that will be used for this
source.
[nonE] None (61)
[``ai] Analog Input (142)
[`C;Pr] Cool Power, Control
Loop (161)
[`h;Pr] Heat Power, Control
Loop (160)
[PWr] Power, Control Loop (73)
[`Lnr] Linearization (238)
[MAt] Math (240)
[``pu] Process Value (241)
[sof;1] Special Function Output
1 (1532)
[`uAr] Variable (245)
None 4960
[offset 80]
0x87 (135)
1 to 4
1
182 35001 uint
RWES
[`Si;A]
[ Si.A] Special Output (1 to 4)
Source Instance A
Set the instance of the
function selected above.
1 to 250 1 4964
[offset 80]
0x87 (135)
1 to 4
3
183 35003 uint
RWES
[`S2;A]
[ SZ.A] Special Output (1 to 4)
Source Zone A
Set the zone of the func-
tion selected above.
0 to 16 0 4968
[offset 80]
0x87 (135)
1 to 4
5
- - - - 35005 uint
RWES
[SFn;b]
[SFn.b] Special Output (1 to 4)
Source Function B
Set the type of function
that will be used for this
source.
[nonE] None (61)
[`C;Pr] Cool Power, Control
Loop (161)
[`h;Pr] Heat Power, Control
Loop (160)
[PWr] Power, Control Loop (73)
[`Lnr] Linearization (238)
[MAt] Math (240)
[`uAr] Variable (245)
None 4962
[offset 80]
0x87 (135)
1 to 4
2
184 35002 uint
RWES
[`Si;B]
[ Si.b] Special Output (1 to 4)
Source Instance B
Set the instance of the
function selected above.
1 to 250 1 4966
[offset 80]
0x87 (135)
1 to 4
4
185 35004 uint
RWES
[`S2;B]
[ SZ.b] Special Output (1 to 4)
Source Zone B
Set the zone of the func-
tion selected above.
0 to 16 0 4970
[offset 80]
0x87 (135)
1 to 4
6
- - - - 35006 uint
RWES
Note:
Some values will be rounded off to fit in the four-character display .
Full values can be read with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E: EEPROM
S: User Set
