Watlow EZ-ZONE ® RMC Module • 113 • Chapter 4 Setup Page
RMC Module • Setup Page
Dis-
play
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[`t;t]
[ t.t] Special Output (1 to 4)
Valve Travel Time
If Function is set to Mo-
torized Valve:
Source A will determine
the valve position.
• Set this time in sec-
onds representing the
time that it will take
the valve to travel be-
tween fully closed and
fully open.
10 to 9,999 seconds 120 5006
[offset 80]
0x87 (135)
1 to 4
0x18 (24)
192 35024 uint
RWES
[``db]
[ db] Special Output (1 to 4)
Dead Band
If Function is set to Mo-
torized Valve:
• Set to the minimum
valve adjustment as
a percentage, rep-
resenting the move-
ment of the valve in a
single action. A small
value improves ac-
curacy and depletes
valve life where a
large value reduces
the number of adjust-
ments (less accurate)
and the wear on the
mechanism.
1.0 to 100.0% 2 5008
[offset 80]
0x87 (135)
1 to 4
0x19 (25)
193 35025 float
RWES
[`o;S1]
[ o.S1] Special Output (1 to 4)
Output 1 Size
If Function is set to Se-
quencer:
• Set Output 1 Size,
as a percentage of
the total capacity of
all output devices, or
vernier output. This
value must be larger
than the values set
for outputs 2 through
4.
0 to 9,999 10 5014
[offset 80]
0x87 (135)
1 to 4
0x1C (28)
- - - - 35028 float
RWES
[`o;S2]
[ o.S2] Special Output (1 to 4)
Output 2 Size
If Function is set to Se-
quencer:
• Set the size of out-
puts 2 through 4 to
represent a percent-
age of the total out-
put capacity. Outputs
2 through 4 will
control using the ON-
OFF algorithm.
0 to 9,999 0 5016
[offset 80]
0x87 (135)
1 to 4
0x1D (29)
- - - - 35029 float
RWES
Note:
Some values will be rounded off to fit in the four-character display .
Full values can be read with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E: EEPROM
S: User Set
