Watlow EZ-ZONE ® RMC Module • 88 • Chapter 4 Setup Page
RMC Module • Setup Page
Dis-
play
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[`C;;Si]
[ C.Si] Current (1 to 4)
Output Source In-
stance
With Current Output
Source Instance, set the
output on which the cur-
rent will be monitored.
1 to 250 1 1416
[offset 50]
0x73 (115)
1 to 4
0x13 (19)
150 15019 uint
RWES
[`Lnr]
[`Set]
Linearization Menu
[``Fn]
[ Fn] Linearization (1 to 4)
Function
Set how this function
will linearize Source A.
[`oFF] Off (62)
[intr] Interpolated (1482)
[Stpd] Stepped (1483)
Off 4528
[offset 70]
0x86 (134)
1 to 4
5
- - - - 34005 uint
RWES
[SFn;A]
[SFn.A] Linearization (1 to 4)
Source Function A
Set the type of function
that will be used for this
source.
[nonE] None (61)
[``Ai] Analog Input (142)
[CUrr] Current (22)
[`C;Pr] Cool Power, Control
Loop (161)
[`h;Pr] Heat Power, Control
Loop (160)
[PWr] Power, Control Loop (73)
[`Lnr] Linearization (238)
[MAt] Math (240)
[``Pu] Process Value (241)
[`SP;C] Set Point Closed, Con-
trol Loop (242)
[`SP;o] Set Point Open, Control
Loop (243)
[`uAr] Variable (245)
None 4520
[offset 70]
0x86 (134)
1 to 4
1
155 34001 uint
RWES
[`Si;A]
[ Si.A] Linearization (1 to 4)
Source Instance A
Set the instance of the
function selected above.
1 or 250 1 4522
[offset 70]
0x86 (134)
1 to 4
2
- - - - 34002 uint
RWES
[`S2;A]
[ SZ.A] Linearization (1 to 4)
Source Zone A
Set the zone of the func-
tion selected above.
0 or 16 0 4524
[offset 70]
0x86 (134)
1 to 4
3
- - - - 34003 uint
RWES
[Unit]
[Unit] Linearization (1 to 4)
Units
Set the units of the out-
put value.
[`Src] Source (1539)
[nonE] None (61)
[`A;tP] Absolute Temperature
(1540)
[`r;tp] Relative Temperature
(1541)
[PWr] Power (73)
[`pro] Process (75)
[``rh] Relative Humidty (1538)
Source 4576
[offset 70]
0x86 (134)
1 to 4
0x1D (29)
156 34029 uint
RWES
Note:
Some values will be rounded off to fit in the four-character display .
Full values can be read with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E: EEPROM
S: User Set
