Watlow EZ-ZONE RMC - Manual (Page 146)

Watlow EZ-ZONE ® RMC Module • 143 • Chapter 5 Profiling Page
Display Step Type
Description
Parameters in Step Type
[StAt]
[StAt]
Step Types
State
A State Step changes set points instantly to the specified
values then maintains the Target Set Points for the desig-
nated time. The state of up to 8 event outputs may be set or
maintained.
[CM;1] Control Mode Loop 1
[CM;2] Control Mode Loop 2
[CM;3] Control Mode Loop 3
[CM;4] Control Mode Loop 4
[tg;S1] Target Set Point Loop 1
[tg;S2] Target Set Point Loop 2
[tg;S3] Target Set Point Loop 3
[tg;S4] Target Set Point Loop 4
[gSE1] Guaranteed Soak Enable 1
[gSE2] Guaranteed Soak Enable 2
[gSE3] Guaranteed Soak Enable 3
[gSE4] Guaranteed Soak Enable 4
[hoUr] Hours
[Min] Minutes
[`SEC] Seconds
[Ent1] Event 1
[Ent2] Event 2
[Ent3] Event 3
[Ent4] Event 4
[Ent5] Event 5
[Ent6] Event 6
[Ent7] Event 7
[Ent8] Event 8
[Subr]
[Subr]
Step Types
Subroutine
A Subroutine Step jumps to a set of subroutine steps that
are common to many profiles. This allows efficiency by uti-
lizing several steps to be accessed and called upon. Once the
subroutine is complete, control is passed back to the main
profile at the next step. The state of up to 8 event outputs
may be set or maintained. This step type not available in
subroutine.
[``SS] Subroutine Step
[``SC] Subroutine Count
[Ent1] Event 1
[Ent2] Event 2
[Ent3] Event 3
[Ent4] Event 4
[Ent5] Event 5
[Ent6] Event 6
[Ent7] Event 7
[Ent8] Event 8
[``JL]
[ JL]
Step Types
Jump Loop
A Jump Loop step will repeat previous steps a number
of times designated in Jump Count. Jump Loops can be
nested up to four deep. The state of up to 8 event outputs
may be set or maintained. This step type not available in
subroutine. Note: Use the Subroutine step type to jump
forward to a set of common steps.
[``JS] Jump Step
[``JC] Jump Count
[Ent1] Event 1
[Ent2] Event 2
[Ent3] Event 3
[Ent4] Event 4
[Ent5] Event 5
[Ent6] Event 6
[Ent7] Event 7
[Ent8] Event 8
[`End]
[ End]
Step Types
End
An End Step will end the profile and set the control modes
and set points to match the End Type. The state of up to 8
event outputs may be set or maintained. The event outputs
will not be set off unless specifically stated in this step. If a
profile does not have an End Step, the profile continues until
step 250, then stops and maintains the last set points and
control modes. In Subroutines, the End Step returns control
back to the next profile step following the call.
[`End] End Type
[Ent1] Event 1
[Ent2] Event 2
[Ent3] Event 3
[Ent4] Event 4
[Ent5] Event 5
[Ent6] Event 6
[Ent7] Event 7
[Ent8] Event 8
