Watlow EZ-ZONE
®
RMC Module
•
122
•
Chapter 4 Setup Page
RMC Module • Setup Page
Dis-
play
Parameter Name
Description
Range
Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[`Si;E]
[ Si.E]
Profile
Source Instance E
Set the instance of the
function selected above.
1 to 250
1
5398
0x7A
(122)
1
0x3C (60)
- - - -
22060
uint
RWE
[`s2;E]
[ SZ.E]
Profile
Source Zone E
Set the zone of the func-
tion selected above.
0 to 16
0
5406
0x7A
(122)
1
0x40 (64)
- - - -
22064
uint
RWE
[SFn;F]
[SFn.F]
Profile
Source Function F
Set the type of function
that will be used for
this source. Source will
be used in profile step
type "Wait for Process
or Event" as "Wait For
Process 2"
[nonE]
None (61)
[``Ai]
Analog Input (142)
[CUrr]
Current (22)
[`C;Pr]
Cool Power, Control
Loop (161)
[`h;Pr]
Heat Power, Control
Loop (160)
[PWr]
Power, Control Loop (73)
[`Lnr]
Linearization (238)
[MAt]
Math (240)
[``Pu]
Process Value (241)
[`SP;C]
Set Point Closed, Con-
trol Loop (242)
[`SP;o]
Set Point Open, Control
Loop (243)
[`uAr]
Variable (245)
None
5392
0x7A
(122)
1
0x39 (57)
- - - -
22057
uint
RWE
[`Si;F]
[ Si.F]
Profile
Source Instance F
Set the instance of the
function selected above.
1 to 250
1
5400
0x7A
(122)
1
0x3D (61)
- - - -
22061
uint
RWE
[`S2;F]
[ SZ.F]
Profile
Source Zone F
Set the zone of the func-
tion selected above.
0 to 16
0
5408
0x7A
(122)
1
0x41 (65)
- - - -
22065
uint
RWE
[SFn;G]
[SFn.g]
Profile
Source Function G
Set the type of function
that will be used for
this source. Source will
be used in profile step
type "Wait for Process
or Event" as "Wait For
Process 3"
[nonE]
None (61)
[``Ai]
Analog Input (142)
[CUrr]
Current (22)
[`C;Pr]
Cool Power, Control
Loop (161)
[`h;Pr]
Heat Power, Control
Loop (160)
[PWr]
Power, Control Loop (73)
[`Lnr]
Linearization (238)
[MAt]
Math (240)
[``Pu]
Process Value (241)
[`SP;C]
Set Point Closed, Con-
trol Loop (242)
[`SP;o]
Set Point Open, Control
Loop (243)
[`uAr]
Variable (245)
None
5394
0x7A
(122)
1
0x3A (58)
- - - -
22058
uint
RWE
Note:
Some values will be rounded off to fit in the four-character display .
Full values can be read with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E:
EEPROM
S:
User Set
