Watlow EZ-ZONE ® RMC Module • 129 • Chapter 5 Profiling Page
RMC Module • Profile Page
Display
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data Type
& Read/
Write
[S;typ]
[S.typ] Step (1 to 250)
Step Type
Select a step type.
[UStP] Unused Step (50)
[SoAH] Soak (87)
[W;PE] Wait For Process
or Event (1542)
[CLoc] Wait For Time
(1543)
[Stat] State (1515)
[Subr] Subroutine Step
(1516)
[``JL] Jump Loop (116)
[`End] End (27)
[``ti] Time (143)
[rAtE] Rate (81)
Unused 5440
[offset 100]
0x79
(121)
1 to (250)
1
- - - - 21001 uint
RWE
[C;M1]
[C.M1] Step (1 to 250)
Control Mode Loop 1
Set the control mode
for this loop.
[AUto] Auto (10)
[`oFF] Off (62)
[MAn] Manual (54)
Auto 5486
[offset 100]
0x79
(121)
1 to (250)
0x18 (24)
- - - - 21024 uint
RWE
[C;M2]
[C.M2] Step (1 to 250)
Control Mode Loop 2
Set the control mode
for this loop.
[AUto] Auto (10)
[`oFF] Off (62)
[MAn] Manual (54)
Auto 5488
[offset 100]
0x79
(121)
1 to (250)
0x19 (25)
- - - - 21025 uint
RWE
[C;M3]
[C.M3] Step (1 to 250)
Control Mode Loop 3
Set the control mode
for this loop.
[AUto] Auto (10)
[`oFF] Off (62)
[MAn] Manual (54)
Auto 5490
[offset 100]
0x79
(121)
1 to (250)
0x1A (26)
- - - - 21026 uint
RWE
[C;M4]
[C.M4] Step (1 to 250)
Control Mode Loop 4
Set the control mode
for this loop.
[AUto] Auto (10)
[`oFF] Off (62)
[MAn] Manual (54)
Auto 5492
[offset 100]
0x79
(121)
1 to (250)
0x1B (27)
- - - - 21027 uint
RWE
[t;SP1]
[t.SP1] Step (1 to 250)
Target Set Point
Loop 1
If step type is Time or
State - enter set point
for this loop. If Rate
step, enter set point
for loops 1, 2, 3 and 4.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
0.0 5442
[offset 100]
0x79
(121)
1 to (250)
2
- - - - 21002 float
RWE
[t;SP2]
[t.SP2] Step (1 to 250)
Target Set Point
Loop 2
If step type is Time or
State - enter set point
for this loop.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
0.0 5494
[offset 100]
0x79 121
1 to (250)
0x1C (28)
- - - - 21028 float
RWE
[t;SP3]
[t.SP3] Step (1 to 250)
Target Set Point
Loop 3
If step type is Time or
State - enter set point
for this loop.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
0.0 5496
[offset 100]
0x79
(121)
1 to (250)
0x1D
(29)
- - - - 21029 float
RWE
[t;SP4]
[t.SP4] Step (1 to 250)
Target Set Point
Loop 4
If step type is Time or
State - enter set point
for this loop.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
0.0 5498
[offset 100]
0x79
(121)
1 to (250)
0x1E (30)
- - - - 21030 float
RWE
Note: Some values will be rounded off to fit in the four-character display . Full values
can be read with other interfaces .
If there is only one instance of a menu, no submenus will appear .
R: Read
W: Write
E: EEPROM
S: User Set
