Watlow EZ-ZONE ® RMC Module • 145 • Chapter 6 Factory Page
RMC Module • Factory Page
Display
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[CUSt]
[FCty]
Custom Setup Menu
[`par]
[ Par] Custom Menu
Parameter 1 to 20
Select the parameters
that will appear in the
Home Page.
The Parameter 1 value
will appear in the
upper display of the
Home Page. It cannot
be changed with the
Up and Down Keys in
the Home Page.
The Parameter 2 value
will appear in the
lower display in the
Home Page. It can be
changed with the Up
and Down Keys, if the
parameter is a writ-
able one.
Scroll through the other
Home Page parame-
ters with the Advance
Key ‰ .
nonE] None
[`l;st] Limit Status
[`L;hy] Limit Hysteresis
[`Lh;S] Limit High Set Point
[`LL;S] Limit Low Set Point
[gSd1] Guaranteed Soak Devia-
tion 1
[P;ACr] Profile Action Request
[P;Str] Profile Start
[idLE] Idle Set Point
[t;tUn] TRU-TUNE+ ® Enable
[`r;rt] Ramp Rate
[`C;hy] Cool Hysteresis
[`C;Pb] Cool Proportional Band
[`h;hy] Heat Hysteresis
[`h;Pb] Heat Proportional Band
[``db] Dead Band
[``td] Time Derivative
[``ti] Time Integral
[`C;Pr] Cool Power
[`h;Pr] Heat Power
[`C;M] User Control Mode
[`AUt] Autotune
[``op] Open Loop Set Point
[AC;SP] Active Set Point
[AC;pu] Active Process Value
[StPt] Set Point
CUSt] Custom Menu
[`A;hy] Alarm Hysteresis
[`A;hi] Alarm High Set Point
[`A;Lo] Alarm Low Set Point
[USr;r] User Restore Set
[`C_F] Display Units
[`i;CA] Input Calibration Offset
[`Pro] Process
- - - - - - - - - - - - - - - - 14005 uint
RWES
[`iid]
iid]
Custom Setup (1 to 20)
Instance ID
Select the instance of
the parameter selected
above to be displayed.
1 to 24 - - - - - - - - - - - - - - - - 14003 uint
RWES
[`LoC]
[FCty]
Security Setting Menu
Note:
Some values will be rounded off to fit in the four-character display . Full values can be read
with another interface .
If there is only one instance of a menu, no submenus will appear .
R: Read
W: Write
E: EE-
PROM
S: User
Set
