Watlow EZ-ZONE
®
RMC Module
•
68
•
Chapter 4 Setup Page
RMC Module • Setup Page
Dis-
play
Parameter Name
Description
Range
Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[SFn;E]
[SFn.E]
Process Value (1 to 4)
Source Function E
Set the type of function
that will be used by
this source to trigger a
switch between Source A
and Source B.
[nonE]
None (61)
[ALM]
Alarm (6)
[`CPE]
Compare (230)
[`Ctr]
Counter (231)
[`dio]
Digital I/O (1142)
[Ent;A]
Profile Event Out A
(233)
[Ent;b]
Profile Event Out B
(234)
[Ent;C]
Profile Event Out C
(235)
[Ent;d]
Profile Event Out D
(236)
[Ent;E]
Profile Event Out E
(247)
[Ent;F]
Profile Event Out F
(248)
[Ent;g]
Profile Event Out G
(249)
[Ent;h]
Profile Event Out H
(250)
[`FUn]
Function Key (1001)
[`lgC]
Logic (239)
[tMr]
Timer (244)
[`uAr]
Variable (245)
None
3408
[offset 70]
0x7E
(126)
1 to 4
5
- - - -
26005
uint
RWES
[`si;E]
[ Si.E]
Process Value (1 to 4)
Source Instance E
Set the instance of the
function selected above.
1 to 250
1
3418
[offset 70]
0x7E
(126)
1 to 4
0xA (10)
- - - -
26010
uint
RWES
[`s2;E]
[ SZ.E]
Process Value (1 to 4)
Source Zone E
Set the zone of the func-
tion selected above.
0 to 16
0
3428
[offset 70]
0x7E
(126)
1 to 4
0xF (15)
- - - -
26015
uint
RWES
[``C;P]
[ C.P]
Process Value (1 to 4)
Cross Over Point
When the value of
source A is <= cross over
point - crossover band
divided by 2 then the
output value will use
source A.
-1999.000 to 9999.000
100.0
3446
[offset 70]
0x7E
(126)
1 to 4
0x18 (24)
26024
float
RWES
[``C;B]
[ C.b]
Process Value (1 to 4)
Cross Over Band
The source will transi-
tion between Source
A and Source B when
within this band at a
progressive rate
-1999.000 to 9999.000
10.0
3448
[offset 70]
0x7E
(126)
1 to 4
0x19 (25)
26025
float
RWES
Note:
Some values will be rounded off to fit in the four-character display .
Full values can be read with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E:
EEPROM
S:
User Set
