Watlow EZ-ZONE ® RMC Module • 91 • Chapter 4 Setup Page
RMC Module • Setup Page
Dis-
play
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[SFn;A]
[SFn.A] Compare (1 to 4)
Source Function A
Set the type of function
that will be used for this
source.
[nonE] None (61)
[``Ai] Analog Input (142)
[CUrr] Current (22)
[`C;Pr] Cool Power, Control
Loop (161)
[`h;Pr] Heat Power, Control
Loop (160)
[PWr] Power, Control Loop (73)
[`Lnr] Linearization (238)
[MAt] Math (240)
[``Pu] Process Value (241)
[`SP;C] Set Point Closed, Con-
trol Loop (242)
[`SP;o] Set Point Open, Control
Loop (243)
[`uAr] Variable (245)
None 4000
[offset 40]
0x80 (128)
1 to 4
1
- - - - 28001 uint
RWES
[`Si;A]
[ Si.A] Compare (1 to 4)
Source Instance A
Set the instance of the
function selected above.
1 to 250 1 4004
[offset 40]
0x80 (128)
1 to 4
3
- - - - 28003 uint
RWES
[`S2;A]
[ SZ.A] Compare (1 to 4)
Source Zone A
Set the zone of the func-
tion selected above.
0 to 16 0 4008
[offset 40]
0x80 (128)
1 to 4
5
- - - - 28005 uint
RWES
[SFn;B]
[SFn.b] Compare (1 to 4)
Source Function B
Set the type of function
that will be used for this
source. This represents
the timer reset signal.
[nonE] None (61)
[``Ai] Analog Input (142)
[CUrr] Current (22)
[`C;Pr] Cool Power, Control
Loop (161)
[`h;Pr] Heat Power, Control
Loop (160)
[PWr] Power, Control Loop (73)
[`Lnr] Linearization (238)
[MAt] Math (240)
[``Pu] Process Value (241)
[`SP;C] Set Point Closed, Con-
trol Loop (242)
[`SP;o] Set Point Open, Control
Loop (243)
[`uAr] Variable (245)
None 4002
[offset 40]
0x80 (128)
1 to 4
2
- - - - 28002 uint
RWES
[`Si;B]
[ Si.b] Compare (1 to 4)
Source Instance B
Set the instance of the
function selected above.
1 to 250 1 4006
[offset 40]
0x80 (128)
1 to 4
4
- - - - 28004 uint
RWES
[`S2;B]
[ SZ.b] Compare (1 to 4)
Source Zone B
Set the zone of the func-
tion selected above.
0 to 16 0 4010
[offset 40]
0x80 (128)
1 to 4
6
- - - - 28006 uint
RWES
Note:
Some values will be rounded off to fit in the four-character display .
Full values can be read with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E: EEPROM
S: User Set
