Watlow EZ-ZONE ® RMC Module • 57 • Chapter 3 Operations Page
RMC Module • Operations Page
Display
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[hoUr]
[hoUr] Profile Status
Hours
Step time remaing in
hours.
0 to 99 0 5434 0x7A
(122)
1
0x4E (78)
- - - - 22078 uint
RW
[min]
[ Min] Profile Status
Minutes
Step time remaing in
minutes.
0 to 59 0 5432 0x7A
(122)
1
0x4D (77)
- - - - 22077 uint
RW
[`seC]
[ SEC] Profile Status
Seconds
Step time remaing in
seconds.
0 to 59 0 5430 0x7A
(122)
1
0x4C (76)
- - - - 22076 uint
RW
No Dis-
play
Profile Status
Wait for Event Source
Value 1
Read the present state
of event input 1.
[`off] Off (62)
[``on] On (63)
- - - - 5346 0x7A
(122)
1
0x22 (34)
- - - - 22034 uint
R
No Dis-
play
Profile Status
Wait for Event Source
Value 2
Read the present state
of event input 1.
[`off] Off (62)
[``on] On (63)
- - - - 5348 0x7A
(122)
1
0x23 (35)
- - - - 22035 uint
R
No Dis-
play
Profile Status
Wait for Event Source
Value 3
Read the present state
of event input 1.
[`off] Off (62)
[``on] On (63)
- - - - 5350 0x7A
(122)
1
0x24 (36)
- - - - 22036 uint
R
No Dis-
play
Profile Status
Wait for Event Source
Value 4
Read the present state
of event input 1.
[`off] Off (62)
[``on] On (63)
- - - - 5352 0x7A
(122)
1
0x25 (37)
- - - - 22037 uint
R
No Dis-
play
Profile Status
Wait for Analog
Source Value 1
Read the present value
of analog source 1.
-1999.000 to 9999.000 - - - - 5414 0x7A
(122)
1
0x44 (68)
- - - - 22068 float
R
No Dis-
play
Profile Status
Wait for Analog
Source Value 2
Read the present value
of analog source 2.
-1999.000 to 9999.000 - - - - 5416 0x7A
(122)
1
0x45 (69)
- - - - 22069 float
R
No Dis-
play
Profile Status
Wait for Analog
Source Value 3
Read the present value
of analog source 3.
-1999.000 to 9999.000 - - - - 5418 0x7A
(122)
1
0x46 (70)
- - - - 22070 float
R
No Dis-
play
Profile Status
Wait for Analog
Source Value 4
Read the present value
of analog source 4.
-1999.000 to 9999.000 - - - - 5420 0x7A
(122)
1
0x47 (71)
- - - - 22071 float
R
Note:
Some values will be rounded off to fit in the four-character display . Full values can be
read with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0
and above .
R: Read
W: Write
E: EEPROM
S: User Set
