Chapter 4 Setup Page
RMC Module • Setup Page
Dis-
play
Parameter Name
Description
Range
Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[otpt]
[`Set]
Output Menu
[``Fn]
[ Fn]
Output Digital (1 to 8)
Function
Select what function will
drive this output.
Note:
Limit function is available
only for the slot in which
the Limit resides.
[`oFF]
Off (62)
[``ai]
Analog Input (142)
[ALM]
Alarm (6)
[`C;Pr]
Cool Power, Control
Loop (161)
[`h;Pr]
Heat Power, Control
Loop (160)
[`CPE]
Compare (230)
[`Ctr]
Counter (231)
[`dio]
Digital I/O (1142)
[Ent;A]
Profile Event Out A
(233)
[Ent;b]
Profile Event Out B
(234)
[Ent;C]
Profile Event Out C
(235)
[Ent;d]
Profile Event Out D
(236)
[Ent;E]
Profile Event Out E
(247)
[Ent;F]
Profile Event Out F
(248)
[Ent;g]
Profile Event Out G
(249)
[Ent;h]
Profile Event Out H
(250)
[`FUn]
Function Key (1001)
[`lgC]
Logic (239)
[`lnr]
Linearization (238)
[mat]
Math (240)
[``pu]
Process Value (241)
[SoF;1]
Special Function Output
1 (1532)
[SoF;2]
Special Function Output
2 (1533)
[SoF;3]
Special Function Output
3 (1534)
[SoF;4]
Special Function Output
4 (1535)
[tMr]
Timer (244)
[`uAr]
Variable (245)
[LiM]
Limit (126)
off
1028
[offset 30]
0x6A
(106)
1 to 8
5
96
6005
uint
RWES
[``Fi]
[ Fi]
Output Digital (1 to 8)
Function Instance
Set the instance of the
function selected above.
1 to 250
1
1030
[offset 30]
0x6A
(106)
1 to 4
6
- - - -
6006
uint
RWES
Note:
Some values will be rounded off to fit in the four-character display .
Full values can be read with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E:
EEPROM
S:
User Set
