Watlow EZ-ZONE ® RMC Module • 67 • Chapter 4 Setup Page
RMC Module • Setup Page
Dis-
play
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[SFn;C]
[SFn.C] Process Value (1 to 4)
Source Function C
Set the type of function
that will be used for this
source.
[nonE] None (61)
[``Ai] Analog Input (142)
[`Lnr] Linearization (238)
[mat] Math (240)
[``Pu] Process Value (241)
[`uAr] Variable (245)
None 3404
[offset 70] 0x7E
(126)
1 to 4
3
- - - - 26003 uint
RWES
[`si;C]
[ Si.C] Process Value (1 to 4)
Source Instance C
Set the instance of the
function selected above.
1 to 250 1 3414
[offset 70] 0x7E
(126)
1 to 4
8
- - - - 26008 uint
RWES
[`s2;C]
[ SZ.C] Process Value (1 to 4)
Source Zone C
Set the zone of the func-
tion selected above.
0 to 16 0 3424
[offset 70] 0x7E
(126)
1 to 4
0x0D (13)
- - - - 26013 uint
RWES
[SFn;d]
[SFn.d] Process Value (1 to 4)
Source Function D
Set the type of function
that will be used for this
source.
[nonE] None (61)
[``Ai] Analog Input, (142)
[`Lnr] Linearization (238)
[mat] Math (240)
[``Pu] Process Value (241)
[`uAr] Variable (245)
None 3406
[offset 70] 0x7E
(126)
1 to 4
4
- - - - 26004 uint
RWES
[`si;d]
[ Si.d] Process Value (1 to 4)
Source Instance D
Set the instance of the
function selected above.
1 to 250 1 3416
[offset 70] 0x7E
(126)
1 to 4
9
- - - - 26009 uint
RWES
[`s2;d]
[ SZ.E] Process Value (1 to 4)
Source Zone D
Set the zone of the func-
tion selected above.
0 to 16 0 3426
[offset 60] 0x7E
(126)
1 to 4
0x0E (14)
- - - - 26014 uint
RWES
Note:
Some values will be rounded off to fit in the four-character display .
Full values can be read with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E: EEPROM
S: User Set
