Watlow EZ-ZONE ® RMC Module • 44 • Chapter 3 Operations Page
RMC Module • Operations Page
Display
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Parameter
ID
Data
Type
& Read/
Write
[`h;Pr]
[ h.Pr] Monitor (1 to 4)
Heat Power
View the current heat
output level.
0.0 to 100.0% - - - - 2244
[offset 70]
0x97 (151)
1 to 4
0xD (13)
- - - - 8011 float
R
[`C;Pr]
[ C.Pr] Monitor (1 to 4)
Cool Power
View the current cool
output level.
-100.0 to 0.0% - - - - 2246
[offset 70]
0x97 (151)
1 to 4
0xE (14)
- - - - 8014 float
R
[`C;SP]
[ C.SP] Monitor (1 to 4)
Closed Loop Active Set
Point
View the set point cur-
rently in effect.
-1,999.000 to 9,999.000°F or
units
-1,128.000 to 5,537.000°C
- - - - 2512
[offset 80]
0x6B (107)
1 to 4
7
- - - - 8029 float
R
[`Pu;A]
[ Pv.A] Monitor (1 to 4)
Process Value Active
View the current filtered
process value using the
control input.
-1,999.000 to 9,999.000°F or
units
-1,128.000 to 5,537.000°C
- - - - 402
[offset 90]
0x68 (104)
1 to 4
0x16 (22)
- - - - 8031 float
R
No Dis-
play
Monitor (1 to 4)
Autotune Status
Read the present status
of Autotune.
[`off] Off (62)
[ts;1p] Waiting for cross 1
positive (119)
[ts;1n] Waiting for cross 1
negative (120)
[ts;2p] Waiting for cross 2
positive (121)
[ts;2n] Waiting for cross 2
negative (122)
[ts;3p] Waiting for cross 3
positive (123)
[ts;3n] Waiting for cross 3
negative (150)
[`mn] Measuring maximum
peak (151)
[`ma] Measuring minimum
peak (152)
[CalC] Calculating (153)
[Cplt] Complete (18)
[``to] Timeout (118)
- - - - 2272
[offset 70]
0x97 (151)
1 to 4
27
- - - - 8027 uint
R
[Loop]
[oPEr]
Control Loop Menu
[`r;En]
[ r.En] Control Loop (1 to 4)
Remote Set Point
Enable this loop to
switch control to the
remote set point.
[``no] No (59)
[`YES] Yes (106)
No 2540
[offset 80] 0x6B
(107)
1 to 4
0x15 (21)
48 7021 uint
RWES
[`C;M]
[ C.M] Control Loop (1 to 4)
Control Mode
Select the method that
this loop will use to
control.
[`off] Off (62)
[AUto] Auto (10)
[MAn] Manual (54)
Auto 2220
[offset 70] 0x97
(151)
1 to 4
1
63 8001 uint
RWES
Note:
Some values will be rounded off to fit in the four-character display . Full values can be
read with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0
and above .
R: Read
W: Write
E: EEPROM
S: User Set
