Setup
5. Analog Port: Pin 12 signals an unsilenced high or medium urgency
alarm. Other pins are used by the Communications Option. Refer to
Chapter 13, “Options and Accessories”.
6. DC Battery Connector: Connection source for battery power cord.
7. AC Inlet: Connection for AC power cord.
8. Humidifier AC Circuit Breaker: Circuit breaker for AC power applied to a
humidifier.
9. Circuit Breaker Cover: Circuit breaker cover (not shown) protects the
Humidifier AC Circuit Breaker and Mains Circuit Breaker switches.
10. Mains Circuit Breaker: Circuit breaker for main AC circuit.
11. Humidifier AC Outlet: Connection for Humidifier AC power cord.
12. Air Inlet Duct and Filter: Filters room air drawn into the ventilator
internal air source.
13. Elapsed Time Meter: Records time when the Power On/Off Switch is on
(
).
14. O
2
Inlet Connector: Connection for oxygen hoses.
15. O
2
Inlet Filter and Water Trap: Filters oxygen entering the ventilator.
16. Potential Equalization Connection: Common grounding point.
17. Cooling Fan Inlet: Allows cooling air to enter the ventilator.
