Chapter 13
13-42
Respironics V200 Ventilator Operator’s Manual
REF 1057983 A
Options and Accessories
VCV Apnea
Respiratory Rate
setting
12.0
0.1 or 1
1.0 – 9.0
10 – 80
BPM
Apnea Peak Flow
setting (same as Peak
Flow setting)
5
1
3 – 140
LPM
Outputs VCV Peak
Flow setting
VCV Apnea Oxygen
Concentration setting
(same as Oxygen
Concentration
setting)
21
1
21 – 100
%
Outputs Oxygen
Concentration
setting
Pressure Support
setting
0
1
0 – 100
cm
H
2
O
Outputs value from
active ventilation
type (VCV or PCV).
When active type
is NPPV then IPAP
– EPAP is used.
VCV Flow Pattern
setting
SQUARE N/A
SQUARE,
RAMP
N/A
Not used
N/A
N/A
N/A
Outputs example
value.
Not used
N/A
N/A
N/A
Outputs example
value.
100% Oxygen setting
ON
N/A
ON
OFF
N/A
Not used
N/A
N/A
N/A
Outputs example
value.
Not used
N/A
N/A
N/A
Outputs example
value.
Not used
N/A
N/A
N/A
Outputs example
value.
Measured total
respiratory rate
0.0
0.1 or 1
0.0 – 9.9
10 - 150
BPM
For values greater
than 150 output
set to 150.
Measured tidal
volume
1.15
0.01
0.00 – 9.99
L
Outputs
for values out of
range.
Measured total
minute volume
0.00
0.01 or 1
0.00 – 9.99
10.0 – 99.9
L
For values out of
range output set
to
99.9.
Measured
spontaneous minute
volume
0.00
0.01 or 0.1
0.00 - 9.99
10.0 – 99.9
L
Outputs
when ventilation
mode is A/C. For
values out of range
output set to 99.9.
Ventilation Report
Description
Example
Resolution
Range
Units
Comments
Table 13-4: Ventilation Report (Sheet 3 of 10)
