Chapter 12
12-2 Respironics V200 Ventilator Operator’s Manual REF 1057983 A
Technical Specifications
Pressure Control
Ventilation Settings,
Ranges and
Resolution
Resolution is one unit unless otherwise noted (cmH
2
O is considered
numerically equivalent to hPa).
Inspiratory Trigger
(I-trigger)
Pressure Sensitivity
Flow Sensitivity
-20 to -0.1 cmH
2
O (hPa) (Resolution is 0.1 cmH
2
O (hPa))
0.5 to 20 LPM (Resolution is 0.1 LPM)
Expiratory Trigger
(E-Cycle)
% Peak Flow 10 to 80% of inspiratory peak flow
Rise Time 0.1 to 0.9 seconds (Resolution is 0.1 second)
%O
2
21% to 100%
Insp. Hold 0 to 2.0 seconds (Resolution is 0.1 second)
Flow Waveform Descending ramp, square
Patient Type Adult/Pediatric
Volume Ventilation Settings, Ranges & Resolution (Continued)
Setting Range
Table 12-3: Volume Ventilation Settings, Ranges and Resolution (Sheet 2 of 2)
Pressure Control Ventilation Settings, Ranges & Resolution
Setting Range
Apnea Rate 1-80 Bpm
Respiratory Rate 1 to 80 Bpm
PCV Pressure 5 to 100 cmH
2
O (hPa) (Relative to PEEP)
Inspiratory Time 0.1 to 9.9 seconds (Resolution is 1 second)
PEEP 0 to 35 cmH
2
O (hPa)
PSV Pressure 0 to 100 cmH
2
O (hPa) (Relative to PEEP)
Inspiratory Trigger
(I-trigger)
Pressure Sensitivity
Flow Sensitivity
-20 to -0.1 cmH2O (hPa) (Resolution is 0.1 cmH2O (hPa))
0.5 to 20 LPM from base flow of 3 LPM above sensitivity (Resolution is
0.1 LPM)
Expiratory Trigger
(E-Cycle)
% Peak Flow 10 to 80% of inspiratory peak flow
Table 12-4: Pressure Control Ventilation Settings, Ranges & Resolution (Sheet 1 of 2)
