Page 177
REF 1057983 A
Respironics V200 Ventilator Operator’s Manual
13-13
Oxygen Manifold Option
The oxygen manifold allows two O
2
cylinders and one wall oxygen supply line
to be used as inputs to the ventilator. Each of the three inlets has a check-
valve that prevents pressure loss when disconnecting from the wall or
cylinders. This allows quick, easy transfer between oxygen supplies without
interruption of flow. Easy transfer of oxygen supply facilitates patient transport
within the facility and allows replacement of one cylinder while operating from
the other.
Figure 13-8: Oxygen Manifold Assembly
Kit Contents
•
(1) Oxygen Manifold Assembly
•
(1) Oxygen Manifold Bracket with Grommet
•
(2) 24-inch Medical Hose Assemblies - Oxygen
•
(1) 4.0mm Allen wrench
•
(2) M6 x 10mm BUTTON HEAD SCREWS, SOC CAP
