Overview of units
9.4 Units—"Milling in C axis" gr
oup
"C-axis lateral surface milling" group
"C-axis lateral surface milling" group
Unit Description Page
G792_NUT_MANT_C
G792 Linear slot
Milling a linear slot
Page 142
G792_LIN_MANT_C G792 Linear slot pattern
Milling of linear slots in a linear pattern
Page 143
G792_CIR_MANT_C G792 Circular slot pattern
Milling of linear slots in a circular pattern
Page 144
G798_Wendelnut_C G798 Helical slot milling
Milling a thread-shaped helical slot
Page 145
G840_FIG_MANT_C G840 Contour milling, figures
Milling figures inside, outside and on the contour
Page 146
G84x_FIG_MANT_C G84x Pocket milling, figures
Roughing out closed figures, inside
Page 149
G802_GRA_MANT_C
G802 Engraving
Engraving characters strings on the lateral surface
Page 152
Unit Description Page
G840_Kon_C_Mant
G840 Contour milling, ICP
Machining ICP contours on the lateral surface inside, outside and on the contour
Page 148
G845_TAS_C_MANT
G845 Pocket milling, ICP
Inside rough-out of closed ICP contours on the lateral surface
Page 151
G840_ENT_C_MANT G840 Deburring
Deburring ICP contours on the lateral surface
Page 153
